ABB F200 Series Residual Current Circuit Breaker 63A 4-Pole 300mA Type AC 400V AC 2CSF204001R3630 F204 AC-63/0,3

ABB 2CSF204001R3630 F204 AC-63/0,3 Residual Current Circuit Breaker provides reliable ground fault protection with a 63A current rating and 4 poles. It is designed for use in commercial and industrial electrical installations where safety and fault detection are critical.

This RCCB features a Type AC tripping characteristic, capable of detecting AC earth leakage currents with a trip sensitivity of 300mA and a rated AC voltage of 400V. The device is designed for DIN rail mounting, facilitating installation and maintenance within standard switchboards and control panels.

The unit comes with a toggle switch for manual reset and is equipped with a mechanical flag to indicate trip status for rapid visual identification of power faults. It has an instantaneous break time, ensuring immediate disconnection under fault conditions, enhancing system safety.

Manufactured to comply with CE and RoHS standards, this circuit breaker meets stringent regulatory and environmental requirements. The screw terminal connection type ensures secure and reliable electrical contact.

The compact dimensions of the breaker are 85mm height, 70mm width, and 85mm depth, providing a space-efficient solution suitable for varied electrical setups. The operating temperature range is from -25 to +55 °C, and it supports frequencies between 50 to 60 Hz, making it adaptable to various electrical grid conditions.

Compact DIN rail mount design ensures easy installation in electrical panels. Features toggle switch reset actuator for quick and safe operation. Instantaneous break time provides rapid disconnection during fault conditions.

Equipped with mechanical flag trip indicator for visual fault notification. Complies with CE and RoHS standards for safety and environmental protection. Screw terminal type ensures secure wiring connections. Optimized for commercial and industrial electrical protection applications.

Operates reliably within a temperature range of -25 to +55 °C and frequency range of 50 to 60 Hz.

This residual current circuit breaker is ideal for industrial, commercial, and residential electrical safety management, protecting electrical circuits from earth leakage currents to prevent electric shock and equipment damage. Explore more products in the Residual Current Circuit Breaker category at EnvMart for comprehensive electrical safety solutions.
