SMC Panel Flow Controller, 500L/min, PNP Output, 0.5 in Pipe, 24V DC PF2A751-F04-67

The SMC PF2A751-F04-67 Panel Flow Controller is an in-line thermal flow switch engineered for accurate fluid flow measurement and control in industrial automation setups. Operating at a maximum flow rate of 500L/min, it features two switched PNP outputs which can be configured to trigger at specific flow rates or volume thresholds, providing versatile application control.

Equipped with a bright 3-digit LED display capable of rotating through 270 degrees, this flow controller allows operators to easily monitor flow values from multiple angles. The controller supports connectivity via an M12 connector terminal and is designed for panel mounting with a maximum pipe size of 0.5 inches, making it adaptable to compact and precise setups.

This device has no moving mechanical parts, leading to reduced maintenance and extended operational longevity. The controller is engineered for minimal pressure loss in fluid systems, improving system efficiency. The unit includes a key lock feature to prevent accidental adjustments or tampering, enhancing operational security.

Robust environmental protection is ensured with an IP65 rating, providing dust-tight and water-resistant qualities, suitable for harsher industrial environments. Electrical safety and compliance are guaranteed with CE certification. The flow controller works within an ambient temperature range of 0°C to 50°C and operates from a 24V DC supply with a low current draw of 170mA, promoting energy efficiency.

This panel flow controller is ideally suited for industrial automation, fluid handling, HVAC applications, and process control environments where precise flow measurement and automated control signals are needed.

Features a PNP control output for reliable signal transmission. Equipped with a clear LED display that rotates 270° for easy viewing. Supports connection via an M12 connector terminal. Capable of handling a maximum pipe diameter of 0.5 inches.

Operates efficiently between 0°C and 50°C operating temperatures. Designed for easy installation with no moving parts and low pressure loss. Provides two switched PNP outputs with a key lock to prevent tampering. Protected against dust and water ingress to IP65 standards.

Certified to CE standards ensuring compliance and safety. Maintains a low current rating of 170mA for energy-efficient operation. Explore the full range of SMC Flow Controllers on EnvMart for reliable industrial and laboratory automation solutions.
