TE Connectivity Series Illuminated Push Button Switch, Latching, Panel Mount, 22.2 mm Cutout, DPDT, Green LED, IP67 AV22

TE Connectivity AV2221E612Q04 is an illuminated push button switch from the AV22 Series, designed for robust panel-mounting applications requiring high reliability and security.

This latching switch features a silver push button actuator with a precise 22.2 mm cutout size, providing a dual pole double throw (DPDT) contact configuration suited for versatile circuit control.

The green LED illumination offers clear visual feedback of the switch status, ideal for control and communication equipment where indication is critical. Engineered with IP67 rating, the switch delivers excellent protection against dust and water, making it suitable for harsh industrial and outdoor environments.

Rated for 250V AC/DC operation with a 3A contact current, it is capable of handling a wide variety of electrical loads safely. The switch operates reliably within a temperature range of -20°C to 55°C, ensuring stable performance under various climatic conditions.

Wire lug terminals provide ease of installation and secure connections. The AV22 Series meets key international standards including RoHS, REACH, UL certification, and EU ELV compliance reflecting its quality and safety.

Typical applications include control and communications equipment, elevators, escalators, and instrumentation devices where a vandal-proof and premium user interface is essential. The switch features a durable silver actuator with a 22.2 mm panel cutout size.

It provides a DPDT contact configuration suitable for dual pole double throw switching. Illuminated operation includes a green LED for visible status indication. The device is rated IP67, ensuring high protection against dust and water ingress.

It supports AC and DC voltages up to 250V with a 3A contact current rating. The switch withstands operating temperatures ranging from -20°C to 55°C. Wire lug terminals provide secure and easy wiring connections. Complies with RoHS, REACH, UL (E46765), and EU ELV standards.

Ideal for industrial, control, elevator, escalator, and instrumentation applications. Explore more in the Switches & Sockets category at EnvMart for high-quality industrial switching solutions.
