TE Connectivity Series Illuminated Push Button Switch, Latching Operation, Panel Mount, 19.2 mm Cutout, SPST Contact AV19
Specifications
| Country of Origin | China |
|---|---|
| Brand | TE Connectivity |
| Length | 19mm |
| Model | AV19 |
| IP Rating | IP67 |
| Mount Type | Panel |
| Series | AV19 |
| Maximum Operating Temperature | 55°C |
| Contact Configuration | SPST |
| Switch Configuration | SPDT |
| Minimum Operating Temperature | -20°C |
| Panel Cutout Size | 19.2 mm |
| Terminal type | Wire Lug |
| Standards/Approvals | EU ELV, REACH, UL FIle No. E46765 |
| LED Colour | Green |
| Switch Operation | Latching |
| Actuator Colour | Silver |
| Contact DC Voltage | 250V |
| Actuator Style | Push Button |
| Switch Contact Current | 3A |
| Contact AC Voltage | 250V ac |
Key Features
- Features a vandal-proof design with rear mounting jam nut for secure installation.
- Silver actuator push button with green LED illumination for clear status indication.
- Single Pole Single Throw (SPST) contact configuration suitable for control circuits.
- IP67 rating ensures dust tight and water ingress protection in industrial environments.
- Operates safely at contact voltages up to 250V AC/DC and contact current rated at 3A.
- Designed to operate in temperatures from -20°C to 55°C for diverse working conditions.
- Panel mount with 19.2 mm cutout size compatible with standard industrial control panels.
- Switch operation is latching, maintaining state until manually reset.
Product Description
TE Connectivity AV19 Series Illuminated Push Button Switch AV19 offers a latching operation designed specifically for panel mounting applications requiring a secure and robust control interface. Its 19.2 mm cutout size suits industrial control panels with space-efficient installation. The push button style actuator with silver color provides a durable and ergonomic interface, illuminated by a green LED that delivers clear visual feedback in operation.
The SPST contact configuration supports straightforward circuit control with a 3 amp contact current rating, handling up to 250 volts AC/DC. Its IP67 ingress protection rating guarantees resistance to dust ingress and protection against water immersion, making it well-suited for demanding industrial, manufacturing, elevator, escalator, and instrumentation equipment environments.
Designed to withstand operating temperatures ranging from -20°C to 55°C, this switch provides reliable performance across varied climatic conditions. It offers a vandal-proof construction using a rear mounting jam nut, enhancing physical durability and security in public or rugged installations.
Compliance with EU ELV, REACH, and UL certifications illustrates safety and environmental standards adherence, providing confidence in deployment within regulated industrial settings. The AV19 series by TE Connectivity is versatile, supporting momentary and latching variants with or without LED indication to fit diverse user interface needs.
Vandal-proof design with secure rear mounting jam nut. Silver actuator with green LED illumination enhances visibility. Single Pole Single Throw (SPST) contact configuration. IP67 rating for dust and water ingress protection.
Supports contact voltage up to 250V AC/DC and 3A current. Operating temperature range from -20°C to 55°C. 19.2 mm panel cutout for compatibility with industry panels. Switch operation is latching for maintained state control.
Certified to EU ELV, REACH, and UL standards. Manufactured in China ensuring consistent quality.
This illuminated push button switch is ideal for industrial control, manufacturing, elevator and escalator control panels, and instrumentation equipment demanding resilient input devices. Explore TE Connectivity AV19 Series and related control switches on EnvMart for trusted industrial automation components.
Explore more products in our Push Button Switches category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a Single Pole Single Throw (SPST) contact configuration suitable for straightforward circuit control.
It operates safely at contact voltages up to 250V AC/DC.
The switch has an IP67 rating, ensuring it is dust-tight and protected against water immersion.
The operating temperature range is from -20°C to 55°C, allowing it to function in diverse working conditions.
This switch requires a 19.2 mm cutout size for panel mounting, making it compatible with standard industrial control panels.
The switch has a contact current rating of 3A, suitable for various control applications.
It features a push button actuator with a silver color, providing an ergonomic interface for users.
Yes, the switch is illuminated by a green LED, which provides clear visual feedback during operation.
The switch is designed for panel mounting, ensuring secure installation with a rear mounting jam nut.
It complies with EU ELV, REACH, and UL standards, indicating adherence to safety and environmental regulations.
The switch is manufactured in China, ensuring consistent quality in production.
This model is ideal for industrial control, manufacturing, elevator and escalator control panels, and instrumentation equipment.
