STMicroelectronics 1-Element Bi-Directional TVS Diode 600W 2-Pin DO-214 SM6T150CA
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 2.45mm |
| Length | 4.6mm |
| Model | SM6T150CA |
| Width | 3.95mm |
| Mount Type | Surface |
| Series | SM6T |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 265V |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 143V |
| Maximum Reverse Stand-off Voltage Vwm | 128V |
| Peak Pulse Power Dissipation Pppm | 600W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 15A |
| Maximum Reverse Leakage Current | 200nA |
Key Features
- Bi-directional diode configuration protects circuits against voltage transients.
- Minimum breakdown voltage of 143V ensures effective surge suppression.
- Maximum reverse stand-off voltage of 128V suits a wide range of applications.
- High peak pulse current rating of 15A enhances robustness during surges.
- Compact DO-214 package with 4.6mm length, 3.95mm width, and 2.45mm height.
- Operating temperature range from -55°C to 150°C accommodates harsh environments.
- Maximum clamping voltage of 265V protects sensitive components efficiently.
- Surface mount mounting type allows easy PCB assembly and high reliability.
Product Description
STMicroelectronics SM6T150CA is a high-performance 1-element bi-directional Transient Voltage Suppressor (TVS) diode designed for protection of sensitive electronics against transient voltage spikes. It delivers a peak pulse power dissipation of 600W, making it suitable for robust surge suppression in industrial, automotive, and electronic equipment applications.
This device features a single diode configuration with a bi-directional direction type and is housed in a surface-mount DO-214 package, which streamlines automated assembly processes. The compact package dimensions of 4.6mm length, 3.95mm width, and 2.45mm height enable space-saving PCB layouts.
The SM6T150CA provides a minimum breakdown voltage of 143V and a maximum reverse stand-off voltage of 128V. It clamps transient voltages effectively, ensuring sensitive components are protected up to a clamping voltage of 265V. The diode supports a peak pulse current of 15A and maintains reliable operation over a wide temperature range from -55°C up to 150°C.
This TVS Diode is ideal for transient voltage suppression in power supply lines, telecommunications, industrial controls, and automotive electronic circuits. Its robust electrical characteristics and compact form factor make it a dependable choice for damage prevention from electrostatic discharge (ESD) and voltage surges.
Bi-directional diode configuration protects circuits against voltage transients. 600W peak pulse power dissipation supports high-energy surge handling. Compact DO-214 surface mount package optimizes PCB space. Wide operating temperature tolerance from -55°C to 150°C.
High peak pulse current of 15A enhances surge robustness. Low maximum reverse leakage current of 200nA reduces power loss. Reliable transient voltage suppression for industrial and automotive applications. Explore a wide range of semiconductor devices and electronic components on EnvMart for your industrial and manufacturing needs.
