Eaton LS-Titan Series Plunger Limit Switch Metal Housing 415V AC 6A 2 NC Contacts 266142 LSM-02

Eaton 266142 LSM-02 plunger limit switch is part of the LS-Titan metal body series designed for dependable position monitoring in industrial and safety-critical applications. This robust limit switch features a heavy-duty metal housing for enhanced durability and protection in demanding environments.

The device includes two normally closed (NC) slow action contacts that provide positive opening for safety circuits, ensuring the machine stops immediately when the protective guard is opened. It operates at a switching AC voltage of 415V and current capacity of 6A, making it suitable for a wide range of industrial equipment.

Rated to IP67 and IP66 standards, this limit switch offers excellent protection against dust and water ingress, supporting use in harsh industrial conditions. The plunger actuator type is effective for monitoring movable guards such as doors, flaps, hoods, and grilles.

Designed for vertical mounting orientation, the switch uses metrical cable entry conduits and cage clamp terminal type for secure wiring. The operating temperature range from -25°C to 70°C enables reliable operation in diverse environments. Its mechanical life of 8 million cycles guarantees durability and low maintenance.

Heavy-duty metal housing for rugged environments. Two normally closed slow action contacts ensure safety. Plunger actuator design for precise guard position monitoring. IP67 and IP66 rated ingress protection. Switching voltage 415V AC, current 6A.

Cage clamp terminals for reliable connections. Vertical mounting with cable entry conduit. Operating temperature range -25°C to 70°C. Mechanical life rated at 8 million cycles for longevity.

The Eaton LS-Titan series limit switches are widely used in industrial automation, manufacturing, and process control to ensure operator safety and machine protection. Their high reliability and compliance with UL, IEC, EN, and CSA standards make them suitable for multiple international applications.

Choose Eaton LS-Titan series plunger limit switch model 266142 LSM-02 for high quality, dependable limit switching in demanding industrial environments. Explore the full range of Limit Switches and safety components available at EnvMart for your automation solutions.
