Wurth Elektronik WR-FFC Series Ribbon Cable 5 Conductors 1 mm Pitch 200 mm Length 686705200001

Wurth Elektronik 686705200001 WR-FFC Series Ribbon Cable is a versatile and reliable flat flexible cable, engineered with 5 copper conductors and a 1 mm pitch spacing. Its 200 mm length enables connection in dense electronic assemblies and compact devices.

The cable jacket is constructed from white polyphenylene ether material, offering excellent insulation and durability. Each cable end is reinforced with a blue PET support tape, which facilitates easy insertion into Zero Insertion Force (ZIF) and Low Insertion Force (LIF) connectors, minimizing damage during assembly.

This ribbon cable series undergoes rigorous flex testing, demonstrating over 20 flex cycles at 180 degrees, which makes it particularly suited for applications demanding high flexibility such as in tight or dynamic electronic devices.

RoHS compliance ensures this product meets environmental and health safety standards. Typical applications include board-to-board connections in LCD appliances, plasma display panels, printers, scanners, DVD players, and notebook computers, where space saving and reliable data transmission are critical.

The Type 2 layout places contacts on opposing cable ends to support various connector configurations. This, combined with the lightweight and low-profile design, results in efficient high-density interconnections in industrial, commercial, and consumer electronics manufacturing.

This ribbon cable features a 1 mm pitch for precise connection layouts. It includes 5 copper conductors with a white polyphenylene ether jacket providing durability. The cable length is 200 mm suitable for compact electronic applications.

Blue PET support tape at cable ends facilitates ZIF and LIF connections with connectors. Highly flexible design allows over 20 flex cycles at 180° enhancing application in complex assemblies. Compliant with RoHS standards ensuring environmental safety.

Ideal for use in LCD appliances, printers, scanners, DVD players, and notebook PCs. Made in China and designed to save space in high-density applications. The WR-FFC series supports Type 2 Flat Flexible Cable jumper configuration with opposite contacts on each cable end.
