WEG CWC Series 3 Pole Motor Control Contactor 24V AC Coil, 12A, 5.5 kW, 690V AC CWC012-10-30D02

Free Delivery in India | Lowest Global Shipping Charges

WEG CWC Series 3 Pole Motor Control Contactor 24V AC Coil, 12A, 5.5 kW, 690V AC CWC012-10-30D02



Category Contactors Brand WEG Condition New

Specifications

Country of Origin	Brazil
Brand	WEG
Function	Motor Control
Length	58mm
Model	CWC012-10-30D02
Depth	52mm
Width	45mm
Mount Type	DIN Rail
Series	CWC
Power Rating	5.5kW
Maximum Operating Temperature	55°C
Minimum Operating Temperature	-25°C
Terminal type	Screw
Number of Poles	3
Standards/Approvals	UL, RoHS, IEC
Contact Voltage	690V ac
Coil Voltage	24V ac
Normal State Configuration	3 NO
Contact Current	12A
Number of Auxiliary Contacts	1
Auxiliary Contact Configuration	1 NO
Operational Current Ie	12A
Control Circuit Voltage Uc	24V ac
Contactor Application	Motor Control
Pole and Throw Configuration	3PST
RS PRO Contactor, 24V ac Coil, 3-Pole, 12 A, 5.5 kW, 3V, 400 VRS Stock No.	277-8407Brand: RS PRO

Key Features

Compact and modular design suitable for DIN Rail mounting.
Operates reliably within -25°C to 55°C temperature range.
Equipped with screw terminal type for secure connections.
Includes one auxiliary contact configured as 1 NO for auxiliary functions.
Compatible with control circuit voltage of 24V AC.
Designed and built according to IEC/EN60947 and DIN VDE 0660 standards.
Rated for operational current Ie of 12A and contact voltage up to 690V AC.
Robust build quality ensures long-term durability and reliability in industrial settings.

Product Description

WEG CWC012-10-30D02 is a professional 3 Pole motor control contactor from the CWC Series, featuring a 24V AC coil and rated for 12A contact current and 5.5 kW power at 690V AC. This contactor is designed for demanding industrial automation applications, providing compact DIN Rail mounting and screw terminal connections for reliable and easy installation.

The device supports operation in ambient temperatures ranging from -25°C to 55°C, making it suitable for varied industrial environments. It includes one auxiliary contact configured as 1 NO, enabling auxiliary control functions. Manufactured in Brazil, it complies with UL, RoHS, and IEC standards ensuring high quality and safety.

Constructed to IEC/EN60947 and DIN VDE 0660 regulations, the WEG CWC series Contactors are modular, compact yet rugged, designed specifically for switching electric motors in commercial and industrial applications. The contactor’s ability to control motors efficiently makes it an ideal component for motor control panels and automation systems.

Compact and modular design suitable for DIN Rail mounting. Operates reliably within -25°C to 55°C temperature range. Equipped with screw terminal type for secure connections. Includes one auxiliary contact configured as 1 NO for auxiliary functions.

Compatible with control circuit voltage of 24V AC. Designed and built according to IEC/EN60947 and DIN VDE 0660 standards. Rated for operational current Ie of 12A and contact voltage up to 690V AC. Robust build quality ensures long-term durability and reliability in industrial settings.

Made in Brazil, meeting UL and RoHS standards.

This WEG contactor is widely used in industrial automation, manufacturing facilities, HVAC motor control, electrical panels, and other commercial applications where reliable motor switching is critical. Browse EnvMart’s extensive range of automation and control gear for compatible products and accessories.
