Socomec 4-Pole DIN Rail Isolator Switch 415V AC 160A 75 kW IP20

Free Delivery in India | Lowest Global Shipping Charges

Socomec 4-Pole DIN Rail Isolator Switch 415V AC 160A 75 kW IP20

Name: Socomec 4-Pole DIN Rail Isolator Switch 415V AC 160A 75 kW IP20
Brand: Socomec
SKU: 187903
Price: 329.77 USD
Availability: InStock



Category Isolator Switch Brand Socomec Condition New

Specifications

Country of Origin	Tunisia
Brand	Socomec
Length	109mm
Model	IP20
Depth	69.9mm
IP Rating	IP20
Width	124.6mm
Mount Type	DIN Rail
Series	Sirco M
Maximum Operating Temperature	70°C
Minimum Operating Temperature	-25°C
Switching Current	160A
Terminal type	Screw
Electrical Phase	3
Handle Colour	Grey
Number of Poles	4
Standards/Approvals	EN, IEC, IS
Switching AC Voltage	415V ac
Switching Power	75kW

Key Features

Manually operated modular multipolar load break switch for industrial applications.
Designed for DIN rail mounting with easy screw terminal connections.
Suitable for three-phase electrical systems with grey handle.
Features visible double breaking and positive break indication for safety.
Complies with IEC 60947-3 international standards for switch disconnectors.
Operates within temperature range of -25°C to 70°C for reliable performance.
Compact dimensions of 124.6mm width, 109mm length, and 69.9mm depth.
Auxiliary contacts available and compatible with 415V AC switching voltage.

Product Description

Socomec 22004016 4-Pole DIN Rail Isolator Switch is a manually operated, modular multipolar load break switch designed primarily for low voltage circuit isolation and machine control circuit safety. It supports a three-phase electrical system and is rated for 415V AC, 160 amperes current, and power handling up to 75 kW. The device features an IP20 ingress protection rating, ensuring protection against solid objects larger than 12 mm.

This isolator switch utilizes a visible double breaking mechanism based on a sliding contact system, ensuring positive break indication and enhanced operator safety during use. It complies with international standards IEC 60947-3, EN, and IS, making it reliable for industrial and commercial applications.

The grey handle is ergonomically designed for easy manual operation, and the switch includes auxiliary contacts for additional control options. It is mounted on a DIN rail for convenient installation and uses screw terminals for secure connections. The switch operates safely within a temperature range from -25°C to 70°C, suiting a wide variety of industrial environments.

Compact in size, the device measures 124.6 mm in width, 109 mm in length, and 69.9 mm in depth, making it suitable for panel installations where space is at a premium. The non-fusible design means it operates without a fuse but provides safe load break capacity and isolation functionality.

Manufactured in Tunisia, this isolator switch is ideal for electrical, automation, industrial manufacturing, and HVAC systems requiring safe and reliable isolation of circuits. It does not support padlock compatibility, reflecting its intended controlled operation environments.

Manually operated modular multipolar load break switch. Visible double breaking with sliding contact system. Complies with IEC 60947-3 and EN standards. DIN rail mounting with screw terminal type connections. Rated for 415V AC, 160A current, and 75 kW switching power.

Operating temperature range from -25°C to 70°C. Grey handle color with auxiliary contacts available. Dimensions: 124.6mm width, 109mm length, 69.9mm depth. Non-fusible disconnect switch, no padlock compatibility. Manufactured in Tunisia for industrial applications.
