Telemecanique Sensors Threaded Barrel Inductive Proximity Sensor M12 x 1, PNP Output, 24V DC, 5 mm Detection XS612B2PAL01M12

Telemecanique Sensors XS612B2PAL01M12 is a threaded barrel Inductive Proximity Sensor designed for metal object detection in automation and control applications. This model features a compact M12 x 1 threaded body with a length of 54.6 mm, providing easy installation in tight spaces. It operates at 24V DC with an output type of PNP and supports a detection range of up to 5 mm, making it ideal for precise sensing tasks in industrial environments.

The sensor housing is crafted from nickel plated brass, delivering robust resistance against mechanical wear and corrosion. Rated at IP67, the sensor is well-protected against dust and water ingress, suitable for harsh manufacturing, automation, and laboratory settings.

Its operational temperature span ranges from -25°C to 70°C, ensuring reliable performance in a variety of temperature conditions. The sensor uses a 4-pin terminal connection and includes a 150mm pigtail lead for connection flexibility. The unshielded design with built-in background suppression allows accurate frontal and lateral metal detection while automatically adapting to surrounding metal environment, reducing false triggering.

This sensor meets international standards including CE, CSA, UL, RoHS, and IEC, guaranteeing product safety and compliance. Its maximum switching frequency of 1kHz enables rapid response for high-speed automation processes. Reverse polarity and short circuit protection features enhance durability and operational safety.

Typical applications include industrial automation, material handling, manufacturing process control, machinery safety, and robotics. The compact and rugged design along with precise metal detection capabilities make it suitable for laboratory instrumentation and HVAC equipment integration.

Features a 5 mm metal detection range suitable for precise sensing applications. Operates at a maximum supply voltage of 24V DC with a maximum allowable voltage of 36V DC. Equipped with a PNP output type and a switching current of 100mA.

Designed with an IP67 rating ensuring protection against dust and water ingress. Capable of operating within temperatures from -25°C to 70°C for wide environmental tolerance. Includes a 150mm pigtail lead for easy wiring and terminal connection via 4-pin interface.

Utilizes an unshielded design for precise frontal and lateral object detection with built-in background suppression. Manufactured with nickel plated brass materials for a durable and corrosion resistant body. Meets CE, CSA, UL, RoHS, and IEC standards and approvals assuring quality and safety compliance.

Functions at a maximum switching frequency of 1kHz suitable for fast switching industrial requirements.

This proximity sensor is well-suited for industrial, manufacturing, automation, laboratory instrumentation, HVAC systems, and commercial applications requiring reliable metal detection. Discover the wide range of sensors available on EnvMart to enhance your control systems.
