STMicroelectronics Gate Driver IC, General Purpose, 1 A Output Current, 14-Pin SOIC Package, 8V - 45V Supply Voltage TDE1747FP
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.65mm |
| Length | 8.75mm |
| Model | TDE1747FP |
| Width | 4mm |
| Mount Type | Surface |
| Series | TDZxJ |
| Output Current | 1A |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -25°C |
| Number of outputs | 5 |
| Pin Count | 14 |
| Maximum Supply Voltage | 45V |
| Minimum Supply Voltage | 8V |
| Driver Type | General Purpose |
Key Features
- Supports a wide supply voltage range from 8 V to 45 V.
- Equipped with 5 output channels for versatile control.
- Designed for surface mount technology with SOIC package type.
- Operates reliably within industrial temperature range from -25°C to 85°C.
- Suitable for high-side power switch applications in automotive and industrial environments.
- Provides low on-resistance power switching with integrated diagnostic and protection features.
- Series TDZxJ ensures quality and performance consistency.
- Non-automotive standard compliant; intended for general industrial use.
Product Description
STMicroelectronics TDE1747FP is a high-performance gate driver IC designed for general purpose high-side switch applications. This device features a 1 A output current capability, packaged in a 14-pin SOIC for surface mount assembly. It supports a broad supply voltage range from 8 V to 45 V, suitable for various industrial and automotive-related power switching requirements.
Built to operate in harsh environments, with an operational temperature range from -25°C to 85°C, the TDE1747FP ensures reliability and robust performance. Its 5 output channels allow for versatile motor and power control scenarios, making it ideal for industrial automation, motor driving, power managementIC, and HVAC systems.
The compact form factor with dimensions of 8.75 mm in length, 4 mm width, and 1.65 mm height integrates easily into dense PCBs. Surface mount packaging with SOIC type ensures ease of manufacturing and reliable solder connections.
This gate driver offers low on-resistance power switch technology combined with precise diagnostic and protection circuitry, improving system efficiency and safety. While it does not conform to specific automotive standards, it remains a trusted choice for general industrial power IC applications.
Supports wide voltage range of 8 V to 45 V for versatile usage. Delivers 1 A output current suitable for driving medium-power loads. Includes 5 output channels for multi-phase or multi-load applications. Compact SOIC 14-pin package suitable for automated surface mount production.
Wide operating temperature range from -25°C to 85°C supports harsh environments. Robust internal diagnostics and protection enhance operational safety. Ideal for motor control, power management, and general industrial electronics.
Part of the TDZxJ series known for reliability and industrial performance. Optimized for applications requiring intelligent power switching.
This product offers a reliable gate driver solution within the field of semiconductors, especially useful in power management IC designs used across industrial, manufacturing, HVAC, and electrical sectors. For users requiring general purpose high-side power switching with robust functionality, the STMicroelectronics TDE1747FP is an excellent choice.
Explore more products within the Gate Drivers category for comprehensive electronic component solutions to meet your application needs on EnvMart.
