Manas Mega SROAT Magnetic Flow Meter MS1010
Specifications
| Display | Digital |
|---|---|
| Diameter | DN400 |
| Body Material | CS |
| Pipe Material | SS304 (non magnetic) |
| Model | MS1010 |
| Ingress Protection | IP-68 |
| Media temperature | 0-80 deg C max |
| Media Pressure | PN10 |
| Power Supply to field coils | Pulsed DC |
| Coil Housing Material | CS (Polyurethene Painted) |
| Liner Material | Hard Ebonite rubber |
| Flanges Material | CS |
| Operating Ambient Temperature (ºC) | 0-60 deg C |
| Primary Flow Sensor | Mega Sroat |
| High accuracy of measurement | 0.5%. of Reading. |
Key Features
- Easy to use
- Easy to install
- Great performance
Product Description
Manas Mega SROAT Magnetic Flow Meter, Electromagnetic flow meters (or magmeters) are a type of velocity or volumetric flow meter that operate pursuant to Faraday's law of electromagnetic induction which states that a voltage will be induced when a conductor moves through a magnetic field. Magmeters can detect the flow rate of conductive fluids only.Other Details:Diameter: DN400 to DN1000 (Higher Diameters on request)Body Material: SS 316/SS 304Coil Housing Material: SS304/SS316Flange Material: SS 316/SS 304Specifications:DNm3/Hr.LPMLPSMLDDNm3/Hr.LPMLPSMLD400452.3897539.816125.66410.88001809.55630159.26502.65443.429450572.5559542.58159.04313.79002290.21938170.32636.17254.965500706.85811780.96196.34916.910002827.43147123.85785.39867.8586001017.87516964.59282.74324.412004071.50167858.341130.97297.7167001385.44123090.69384.84533.214005541.76592362.751539.379133.0027501590.4326507.17441.78638.116007238.223120637.12010.618173.7176.21
- Highly durable
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The body and flanges of the flow meter are made from stainless steel (SS 316/SS 304).
The media temperature range for this model is from 0 to 80 degrees Celsius maximum.
This model requires a pulsed DC power supply for its field coils.
The flow meter provides a high accuracy of measurement, with an accuracy rating of 0.5% of the reading.
The Manas Mega SROAT Magnetic Flow Meter MS1010 has an ingress protection rating of IP-68.
The maximum media pressure for this model is PN10.
The operating ambient temperature range for this model is from 0 to 60 degrees Celsius.
The coil housing is made from carbon steel (CS) and is polyurethane painted, while the liner material is hard ebonite rubber.
This magnetic flow meter is designed to measure the flow rate of conductive fluids only.
The installation requirements are not explicitly detailed, but it is designed for easy installation and setup.
