KEMET R53B Film Capacitor 560 nF ±10% 800 V DC 350 V AC Through Hole Mount R53BN35605000K
Specifications
| Country of Origin | China |
|---|---|
| Display | screen |
| Brand | KEMET |
| Height | 18.5mm |
| Length | 26.5mm |
| Model | R53BN35605000K |
| Packaging | Tape & Reel |
| Width | 10mm |
| Mount Type | Through Hole |
| Series | R53B |
| Maximum Operating Temperature | 125°C |
| Tolerance | ±10 % |
| Capacitance | 560nF |
| Minimum Operating Temperature | -40°C |
| Dissipation Factor | 0.3% |
| Standards/Approvals | IEC 60384-14 |
| Package/Case | Plastic |
| Pin Count | 2 |
| Rated AC Voltage | 350V ac |
| Rated DC Voltage | 800V dc |
| Lead Pitch | 22.5mm |
| Automotive Standard | AEC-Q200 |
Key Features
- This film capacitor features metallized polypropylene film construction with self-extinguishing resin encapsulation.
- Meets automotive standard AEC-Q200 for durability and reliability in automotive environments.
- Wide operating temperature range from -40°C to 125°C.
- Lead pitch of 22.5 mm for standard through-hole mounting.
- Plastic case package compliant with IEC 60384-14 and X2 CLASS safety standards.
- Low dissipation factor of 0.3% to minimize power loss.
- Capacitance of 560 nF with ±10% tolerance.
- Rated DC voltage 800 V; AC voltage 350 V.
Product Description
The KEMET R53BN35605000K is a high-quality film capacitor designed with metallized polypropylene film encapsulated in a self-extinguishing resin meeting UL 94 V-0 standards. This capacitor is optimized for reliability under harsh environmental conditions and complies with the automotive electronics council's AEC-Q200 standards, making it ideal for automotive and industrial electronics applications.
It provides a capacitance of 560 nF with a tolerance of ±10%, supporting rated voltages of 800 V DC and 350 V AC. The capacitor operates reliably within a temperature range from -40°C to 125°C, ensuring performance stability across various industrial and automotive environments.
The through-hole mount type with a lead pitch of 22.5 mm and plastic package case facilitates ease of integration on printed circuit boards, with pin count of 2. Its dimensions - 26.5 mm in length, 18.5 mm in height, and 10 mm in width - make it compact while meeting IEC 60384-14 standards and X2 class specifications for safety and quality.
This capacitor features self-healing properties and low dissipation factor (0.3%) to reduce energy loss in circuits. It is supplied in tape and reel packaging, suitable for modern automated PCB assembly lines and manufacturing.
Typical industrial uses include automotive electronics systems, power electronics, control circuits, and various manufacturing applications requiring robust, reliable passive components.
This film capacitor features metallized polypropylene film construction with self-extinguishing resin encapsulation. Meets automotive standard AEC-Q200 for durability and reliability in automotive environments. Wide operating temperature range from -40°C to 125°C.
Lead pitch of 22.5 mm for standard through-hole mounting. Plastic case package compliant with IEC 60384-14 and X2 CLASS safety standards. Low dissipation factor of 0.3% to minimize power loss. Capacitance of 560 nF with ±10% tolerance.
Rated DC voltage 800 V; AC voltage 350 V. Two-pin configuration for secure PCB installation. Supplied in tape & reel packaging for manufacturing efficiency. Discover excellent performance and compliance in the KEMET film capacitor range for your electronic component needs at EnvMart.
Explore more products in our Film Capacitors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance of this model is 560 nF with a tolerance of ±10%.
It has a rated DC voltage of 800 V and a rated AC voltage of 350 V.
This capacitor operates reliably within a temperature range from -40°C to 125°C.
The lead pitch for this through-hole mount capacitor is 22.5 mm.
It is supplied in tape and reel packaging, making it suitable for automated PCB assembly.
It complies with IEC 60384-14 and meets the automotive standard AEC-Q200 for durability and reliability.
The dissipation factor is 0.3%, which helps minimize power loss.
The dimensions are 26.5 mm in length, 18.5 mm in height, and 10 mm in width.
It features metallized polypropylene film construction with self-extinguishing resin encapsulation.
This model has a pin count of 2, which is standard for its configuration.
It is suitable for automotive electronics systems, power electronics, control circuits, and various manufacturing applications.
The country of origin for this capacitor is China.
