Siemens Inverter Drive, 1.5 kW Power Rating, 3 Phase, SINAMICS G115D Series 480V, 6SL3520-3XE01-5AB0

Name: Siemens Inverter Drive, 1.5 kW Power Rating, 3 Phase, SINAMICS G115D Series 480V, 6SL3520-3XE01-5AB0
Brand: Siemens
SKU: 178106
Price: 2383.35 USD
Availability: InStock



Category Inverter Drives Brand Siemens Condition New

Specifications

Country of Origin	United Kingdom
Brand	Siemens
Model	6SL3520-3XE01-5AB0
IP Rating	IP65, IP66
Mount Type	Panel
Series	SINAMICS G115D
Overall Width	380mm
Power Rating	1.5kW
Maximum Operating Temperature	55°C
Output Frequency	550Hz
Minimum Operating Temperature	-30°C
Number of Phases	3
Maximum Output Current	6.2A
Standards/Approvals	CE, C-Tick (RCM), EAC, KCC, REACH, SEMI F47
Maximum Supply Voltage	480V
Overall Depth	129mm
Minimum Supply Voltage	380V
Better World Claim	Saves Energy

Key Features

Part of the SINAMICS G115D series designed for high efficiency.
Supports maximum output current of 6.2 A.
Designed for panel mount installation with IP65 and IP66 ratings.
Operates within supply voltage range of 380 - 480V.
Output frequency capability up to 550 Hz.
Works reliably in temperatures from -30°C to 55°C.
Measures 380 mm in width and 129 mm in depth for compact installations.
Includes integrated safety features such as STO function and fail-safe digital inputs.

Product Description

Siemens 6SL3520-3XE01-5AB0 is an industrial-grade inverter drive from the SINAMICS G115D series providing 1.5 kW power output and three-phase operation with a rated maximum current of 6.2 A. This panel-mounted converter supports SIMOGEAR 2KJ8 geared motors paired with three-phase asynchronous motors (efficiency class IE3) or synchronous reluctance motors (efficiency class IE4), delivering energy-efficient drive solutions.

This inverter drive is engineered for demanding horizontal conveyor system applications, offering everything from simple speed control to advanced encoderless vector control. Its integrated safety functions include safe torque off (STO) and fail-safe digital inputs, enhancing operational safety in industrial environments.

With an IP65 and IP66 protection rating, this drive is robust and suitable for harsh conditions, operating effectively in ambient temperatures ranging from minus 30 degrees Celsius to 55 degrees Celsius. The compact design allows installation directly on machines without the need for control cabinets, reducing required space and cooling demands.

The overall dimensions of 380 mm width and 129 mm depth make this unit well-suited for modular setups. It complies with multiple international standards such as CE, C-Tick (RCM), EAC, KCC, REACH, and SEMI F47, ensuring quality and regulatory adherence.

This product is manufactured in the United Kingdom and qualifies as a Better World product by contributing to energy savings and sustainability goals. It supports industry use cases including manufacturing automation, conveyor systems, material handling, and general industrial motor drive applications.

Part of the SINAMICS G115D modular distributed drive system for seamless motor and gearbox integration. Supports high-efficiency asynchronous and synchronous motors compliant with IE3 and IE4 standards. IP65/IP66 rated enclosures protect from dust and water ingress for reliable operation.

Integrated safety and user-friendly modular design reduces installation time and space requirements. No control cabinet needed, enabling machine-mounted installation with lower cooling needs. Operates over wide temperature range ideal for diverse industrial environments.

Designed for conveyor belt speed regulation and sophisticated vector control without encoders. Certified with multiple international standards for worldwide compliance. Improves energy efficiency and operational sustainability in industrial settings.

Explore this Siemens inverter drive and other industrial automation products at EnvMart for robust, efficient drive solutions tailored to your application needs.

Explore more products in our Inverter Drives category.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The inverter drive has a power rating of 1.5 kW.

It supports a maximum output current of 6.2 A.

It operates within a supply voltage range of 380 - 480V.

The output frequency capability is up to 550 Hz.

The overall dimensions are 380 mm in width and 129 mm in depth.

It operates effectively in temperatures ranging from -30°C to 55°C.

It is designed to work with SIMOGEAR 2KJ8 geared motors and three-phase asynchronous motors (efficiency class IE3) or synchronous reluctance motors (efficiency class IE4).

This model has an IP65 and IP66 rating, providing protection against dust and water ingress.

It includes integrated safety features such as safe torque off (STO) and fail-safe digital inputs.

Yes, it is designed for panel mount installation.

It complies with multiple international standards including CE, C-Tick (RCM), EAC, KCC, REACH, and SEMI F47.

It is suitable for applications including manufacturing automation, conveyor systems, material handling, and general industrial motor drive applications.
