Siemens Inverter Drive SINAMICS G115D Series 2.2 kW 3 Phase 380-480V 11.8 A 6SL3520-3XA62-2AF0

Siemens 6SL3520-3XA62-2AF0 SINAMICS G115D series inverter drive delivers 2.2 kW power rated at 3 phase operation with supply voltages ranging from 380 to 480 V. This inverter drive supports a maximum output current of 11.8 A and an output frequency up to 550 Hz, making it ideal for precise motor speed and torque control in industrial applications.

The device is engineered with a rugged IP65 and IP66 rated enclosure, providing robust protection against dust and water, thereby ensuring reliable operation in harsh environments. Its operational temperature range from -30°C to 55°C enables deployment in extreme thermal conditions. Compactly designed with overall dimensions of 156 mm length, 380 mm width, and 129 mm depth, it suits installation in space-constrained machinery.

This drive incorporates integrated safety features such as Safe Torque Off (STO) with fail-safe digital input or PROFIsafe options to enhance operational safety. The modular and user-friendly design allows quick installation, cabling, and commissioning, eliminating the need for a control cabinet and reducing cooling requirements.

The SINAMICS G115D system is fully preconfigured to work with SIMOGEAR 2KJ8 geared motors including three-phase asynchronous motors with IE3 efficiency class or synchronous reluctance motors with IE4 class high efficiency. It is particularly suited for horizontal conveyor system applications requiring both simple speed control and sophisticated encoderless vector control.

The SINAMICS G115D series supports 380-480V supply voltage for versatile deployment. Maximum output current rated at 11.8 A for efficient motor operation. Equipped with IP65 and IP66 ratings for robust protection against dust and water ingress.

Operating temperature range from -30°C to 55°C suitable for diverse environments. Output frequency capability up to 550 Hz enabling flexible motor speed control. Compact dimensions with 156 mm length, 380 mm width, and 129 mm depth for easy integration.

Integrated safety functionality offering Safe Torque Off (STO) with fail-safe inputs. Designed as a modular, user-friendly, and space-saving solution suitable for conveyor system applications. Conforms to multiple approvals including CE, cUL, UL, REACH, and SEMI F47 standards.

Manufactured in the United Kingdom ensuring high-quality engineering standards.

This inverter drive is ideal for industrial, manufacturing, automation, and conveyor control applications requiring reliable energy-efficient motor management. It enables enhanced operational safety and energy savings as part of Siemens' Better World product initiative.

Explore the wide range of Inverter Drives from Siemens and other quality brands available at EnvMart to optimize your industrial automation needs.
