Siemens Inverter Drive 4 kW 3 Phase SINAMICS G115D Series 480V 20.4 A 6SL3520-0XH04-0AB0
Specifications
| Country of Origin | United Kingdom |
|---|---|
| Brand | Siemens |
| Model | 6SL3520-0XH04-0AB0 |
| IP Rating | IP65, IP66 |
| Mount Type | Wall |
| Overall Length | 240mm |
| Series | SINAMICS G115D |
| Overall Width | 425mm |
| Power Rating | 4kW |
| Maximum Operating Temperature | 55°C |
| Output Frequency | 550Hz |
| Minimum Operating Temperature | -30°C |
| Number of Phases | 3 |
| Maximum Output Current | 20.4A |
| Standards/Approvals | SEMI F47, WEEE Directive, UL, CE, cUL, EAC, EMC Directive 2014/30/EC, KCC, Low Voltage Directive 2014/35/EC, RCM (C-Tick), REACH, RoHS |
| Maximum Supply Voltage | 480V |
| Overall Depth | 169mm |
| Minimum Supply Voltage | 380V |
| Better World Claim | Saves Energy |
| Compatible Motor Type | 3 Phase AC Motors |
Key Features
- Part of the SINAMICS G115D series designed for durable industrial use.
- Wall mount installation with IP65 and IP66 protection ratings.
- Compatible with three phase AC motors, including SIMOGEAR 2KJ8 geared motors.
- Supports output frequencies up to 550 Hz with sophisticated encoderless vector control.
- Operates reliably in temperatures from -30°C to 55°C.
- Integrated safety features include STO function with fail safe digital input or PROFIsafe support.
- User-friendly modular design requires no control cabinet, saving space and cooling needs.
- Meets international standards such as UL, CE, cUL, EAC, and complies with RoHS and REACH regulations.
Product Description
Siemens 6SL3520-0XH04-0AB0 Inverter Drive is a high performance industrial converter from the SINAMICS G115D series, delivering 4 kW power for three-phase motor control. It supports a supply voltage range of 380V to 480V and a maximum output current of 20.4 A, making it suitable for a variety of industrial automation and conveyor system applications.
This inverter drive is engineered for horizontal conveyor systems, offering simple speed control as well as advanced encoderless vector control for smooth operation. Its wall mount design is rated IP65 and IP66, providing excellent protection against dust and water ingress. The robust housing enables operation in harsh environments with ambient temperatures from -30°C to +55°C.
The unit supports compatibility with SIMOGEAR 2KJ8 geared motors and three phase asynchronous motors with efficiency class IE3, as well as high efficiency synchronous reluctance motors (IE4). Integrated safety features include the STO (Safe Torque Off) function with fail safe digital input or PROFIsafe interface, ensuring compliance with industrial safety regulations.
The compact modular design facilitates quick and easy installation, cabling, and commissioning without the need for a control cabinet. This reduces space requirements and cooling system needs, enhancing overall system efficiency. Siemens has ensured this product meets multiple global standards, including SEMI F47, WEEE Directive, UL, CE, cUL, EAC, EMC Directive, KCC, Low Voltage Directive, RCM (C-Tick), REACH, and RoHS compliance.
With overall dimensions of 425 mm width, 240 mm length, and 169 mm depth, the inverter drive integrates seamlessly into industrial setups. It is designed to save energy and contribute to sustainable industrial operations, aligning with Siemens’ Better World initiative. This inverter drive is made in the United Kingdom and is suitable for industrial, manufacturing, automation, and HVAC applications requiring reliable and efficient motor control.
Part of the SINAMICS G115D series designed for durable industrial use. Wall mount installation with IP65 and IP66 protection ratings. Compatible with three phase AC motors, including SIMOGEAR 2KJ8 geared motors. Supports output frequencies up to 550 Hz with sophisticated encoderless vector control.
Operates reliably in temperatures from -30°C to 55°C. Integrated safety features include STO function with fail safe digital input or PROFIsafe support. User-friendly modular design requires no control cabinet, saving space and cooling needs.
Meets international standards such as UL, CE, cUL, EAC, and complies with RoHS and REACH regulations. Explore more Siemens Inverter Drives and industrial motor control products at EnvMart for your automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Siemens inverter drive has a power rating of 4 kW.
It can handle a maximum output current of 20.4 A.
This model operates reliably in temperatures ranging from -30°C to 55°C.
It is compatible with three-phase AC motors, including SIMOGEAR 2KJ8 geared motors and high efficiency synchronous reluctance motors (IE4).
The inverter drive supports output frequencies up to 550 Hz.
The overall dimensions are 425 mm in width, 240 mm in length, and 169 mm in depth.
It has an IP rating of IP65 and IP66, providing protection against dust and water ingress.
No, its user-friendly modular design requires no control cabinet, which saves space and reduces cooling needs.
Integrated safety features include the Safe Torque Off (STO) function with fail-safe digital input or PROFIsafe support.
It meets multiple international standards, including UL, CE, cUL, EAC, and complies with RoHS and REACH regulations.
The inverter drive is manufactured in the United Kingdom.
It is part of the SINAMICS G115D series designed for durable industrial use.
