ABB Tmax XT Molded Case Circuit Breaker 3-Pole 125A 50kA Breaking Capacity Fixed Mount 1SDA068056R1 XT3N 250 TMD 125A FF
Specifications
| Country of Origin | Italy |
|---|---|
| Range | Tmax XT |
| Brand | ABB |
| Height | 150mm |
| Model | 1SDA068056R1 XT3N 250 TMD 125A FF |
| Depth | 70mm |
| Width | 140mm |
| Mount Type | Fixed |
| Current Rating | 125A |
| Series | Tmax XT |
| Terminal type | Fixed |
| Breaking Capacity | 50kA |
| Number of Poles | 3 |
| Standards/Approvals | CE, IEC, RoHS |
| Rated AC Voltage | 690V ac |
| Rated DC Voltage | 500V dc |
| Better World Claim | Designed for Disassembly |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Lever |
| Rated current (In) | 125 A In |
| Rated frequency (f) | 50/60 Hz |
| Rated voltage (Ur) | 690 V |
| Rated impulse withstand voltage (Uimp) | 8 kV |
Key Features
- Designed for fixed mounting with front terminals for secure connections.
- Equipped with a thermal magnetic tripping mechanism for reliable circuit protection.
- Rated AC voltage of 690V and DC voltage of 500V for versatile electrical applications.
- Complies with CE, IEC, and RoHS standards ensuring safety and environmental compliance.
- Compact dimensions with 150mm height, 140mm width, and 70mm depth for space-saving installations.
- Features a lever-type reset actuator for easy manual operation.
- Offers rated uninterrupted current of 160A ensuring continuous operation under load.
- Impulse withstand voltage rated at 8 kV for strong electrical stress tolerance.
Product Description
ABB 1SDA068056R1 XT3N 250 TMD 125A FF Molded Case Circuit Breaker is a premium electrical protection device featuring a 3-pole configuration with fixed mounting, suitable for industrial, commercial, and automation applications. It delivers a robust current rating of 125A and a breaking capacity of 50 kA, ensuring high performance in demanding environments.
This circuit breaker supports rated AC voltage of 690V and DC voltage of 500V with a rated frequency of 50/60 Hz, making it adaptable to various power systems. It incorporates a thermal magnetic trip mechanism to protect circuits against overloads and short circuits effectively. The device includes front fixed terminals, providing secure and reliable electrical connections.
Compliant with CE, IEC, and RoHS standards, this breaker not only meets stringent safety and quality requirements but also aligns with environmental sustainability efforts. With compact dimensions of 150mm height, 140mm width, and 70mm depth, it is designed for efficient space utilization in panel installations.
The reset actuator type is a lever, allowing straightforward manual resetting after tripping events. Rated for an uninterrupted current of 160A and impulse withstand voltage of 8 kV, it offers enhanced durability under electrical stress. Manufactured in Italy, this ABB breaker supports the company's commitment to ecological design with features enabling easy disassembly for recycling.
Fixed mounting with front terminals for secure installation. Thermal magnetic tripping for precise circuit protection. Electrical ratings: 125A current, 690V AC voltage, 500V DC voltage, 50/60 Hz frequency. Compact size ideal for standard panel layouts.
Standards compliance: CE, IEC, RoHS ensuring reliability and safety. Lever reset actuator for user-friendly operation. Impulse withstand voltage of 8 kV for high electrical endurance. Designed for sustainability and disassembly.
This ABB Tmax XT Molded Case Circuit Breaker is suitable for use in industrial electrical panels, automated manufacturing setups, commercial buildings, and any environment requiring dependable circuit interruption for safety and maintenance. Its reliable construction and compliance make it a preferred choice for engineers and installers.
Explore more high-quality ABB electrical protection products at EnvMart, your trusted industrial catalog partner.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The breaking capacity of this molded case circuit breaker is 50 kA, allowing it to effectively interrupt high fault currents.
This model supports a rated AC voltage of 690V and a rated DC voltage of 500V, making it versatile for various electrical applications.
The current rating of this circuit breaker is 125A, suitable for a range of industrial and commercial applications.
This unit features a 3-pole configuration, which is standard for many electrical distribution systems.
It has compact dimensions of 150mm in height, 140mm in width, and 70mm in depth, allowing for efficient installation in panels.
It incorporates a thermal magnetic tripping mechanism, providing reliable protection against overloads and short circuits.
The rated uninterrupted current for this model is 160A, ensuring continuous operation under load conditions.
This circuit breaker has an impulse withstand voltage rating of 8 kV, which helps it endure strong electrical stress.
It complies with CE, IEC, and RoHS standards, ensuring safety and environmental compliance in its design and operation.
It features a lever-type reset actuator, allowing for easy manual operation after a tripping event.
This model is manufactured in Italy, reflecting ABB's commitment to quality and ecological design.
Yes, it is designed for fixed mounting with front terminals, ensuring secure and reliable electrical connections.
