ABB Tmax XT Molded Case Circuit Breaker 4-Pole 63A 200 kA Breaking Capacity Fixed 1SDA068012R1 XT2V 160 Ekip I 63A FF

ABB 1SDA068012R1 XT2V 160 Ekip I 63A FF Molded Case Circuit Breaker is engineered for robust electrical protection in industrial, commercial, and manufacturing installations. This 4-pole MCCB provides a fixed mounting with front terminals, suitable for high-demand operational environments requiring reliable trip settings and durable construction.

This breaker offers a rated uninterrupted current of 160 A with a nominal current rating of 63 A and a high breaking capacity of 200 kA, ensuring safe interruption of fault currents. Operating voltage is rated at 690 V AC, adaptable to standard power systems with frequencies of 50/60 Hz. The impulse withstand voltage rating of 8 kV further enhances its protective performance against transient surges.

The device incorporates a solid state release tripping mechanism within the Ekip I series, delivering precise and consistent opening in fault conditions. The lever reset actuator provides manual control for resetting post-trip conditions. This circuit breaker is part of ABB’s Better World initiative, designed for environmental sustainability including ease of disassembly for recycling or maintenance.

Compact dimensions of 130 mm height, 120 mm width, and 82.5 mm depth allow integration into various panel configurations with minimal space requirements. It holds certifications including CE, IEC, and RoHS, attesting to its compliance with rigorous international electrical and environmental standards. Manufactured in Italy, the quality assurance reflects ABB’s commitment to reliability and performance.

Includes 4 poles with fixed terminal mounting for stable installation. Operates at rated voltage of 690 V AC and frequency of 50/60 Hz. Equipped with solid state tripping mechanism ensuring precise response. Features lever reset actuator for easy manual control.

Designed as a Better World product with claim for disassembly and sustainability. Compact dimensions: 130 mm height, 120 mm width, and 82.5 mm depth. Complies with CE, IEC, and RoHS standards guaranteeing quality and safety.

Manufactured in Italy with high-quality materials and design integrity.

This Molded Case Circuit Breaker is ideal for electrical distribution and protection in industrial electrical panels, manufacturing plants, commercial buildings, and HVAC systems. It ensures circuit safety under overload and short circuit conditions while enabling easy integration and servicing.
