TE Connectivity DuraSeal Red Insulated Female Spade Connector Crimp 6.35 x 0.8 mm Tab Size B-106-4631
Specifications
| Country of Origin | Mexico |
|---|---|
| Brand | TE Connectivity |
| Colour | Red |
| Orientation | Straight |
| Model | B-106-4631 |
| Gender | Female |
| Insulation | Insulated |
| Overall Length | 1.85in |
| Contact Material | Brass |
| Series | DuraSeal |
| Termination Type | Crimp |
| Insulation Material | Nylon |
| Standards/Approvals | UL listed component, file E87681 (butt splices and terminals except quick connect terminals), file E157833 (quick connect terminals) |
| Contact Plating | Tin |
| Minimum Wire Size mm² | 0.3mm² |
| Maximum Wire Size mm² | 0.9mm² |
| Minimum Wire Size AWG | 22AWG |
| Maximum Wire Size AWG | 18AWG |
| Tab Width | 0.25in |
| Tab Thickness | 0.032in |
| Tab Size | 6.35 x 0.8 mm |
| Blade terminal | tin plated brass |
Key Features
- Constructed with brass contact material plated with tin for durability.
- Features nylon insulation for enhanced electrical protection.
- Designed for a straight orientation and insulated termination.
- Suitable for wire sizes ranging from 0.3 mm² (22 AWG) to 0.9 mm² (18 AWG).
- Includes UL listed approvals ensuring industry safety standards compliance.
- Overall length measures 1.85 inches for compact installation.
- Offers heat-shrinkable protection providing waterproof and strain relief connection.
- Ideal for automotive, marine, and environmental sealing applications.
Product Description
TE Connectivity B-106-4631 DuraSeal Red Insulated Female Spade Connector is designed to provide a reliable, waterproof, and strain-relieved crimp termination. It supports tin-plated or bare copper stranded wires with insulation rated at least 75°C. This connector is engineered with a 6.35 x 0.8 mm blade terminal and is compatible with wire sizes from 22 AWG (0.3 mm²) to 18 AWG (0.9 mm²).
Made with brass contact material and tin plating, its nylon insulated sleeve and heat-shrinkable design ensure durability and environmental protection. The straight orientation facilitates easy connection and installation.
The connector is UL listed, meeting file E87681 and E157833 safety approvals, making it reliable for use in rigorous environments including automotive and marine sectors where waterproof sealing is critical.
Its operating temperature range is broad, accommodating between -55°C and 125°C, ensuring functionality in diverse conditions. The heat-shrinkable sleeve contains a hot melt adhesive that, when heated after crimping, seals the joint against moisture and mechanical stress.
Brass contacts with tin plating ensure excellent conductivity and corrosion resistance. Nylon insulation adds electrical safety and mechanical protection. Waterproof sealing suitable for harsh environments. Compatible with wire sizes from 22 AWG to 18 AWG for flexible applications.
Compact 1.85-inch length allows tight space installations. UL certifications affirm product safety and quality. Designed for automotive, marine, and tooling installation needs with robust connection integrity.
Choose TE Connectivity DuraSeal connectors for assured quality and protection in electrical wiring projects. Explore more connectors and spade terminal options in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is compatible with wire sizes ranging from 22 AWG (0.3 mm²) to 18 AWG (0.9 mm²).
The overall length of this connector is 1.85 inches, allowing for compact installations.
It is constructed with brass contact material that is tin plated, and features nylon insulation for enhanced electrical protection.
The tab size of this connector is 6.35 x 0.8 mm.
This connector operates effectively within a temperature range of -55°C to 125°C.
Yes, this connector is UL listed, meeting safety standards under file E87681 and E157833.
It uses a crimp termination type for secure connections.
The connector is designed for a straight orientation, facilitating easy installation.
It is suitable for automotive, marine, and environmental sealing applications.
The heat-shrinkable sleeve provides waterproof sealing and strain relief for the connection.
This model is a female spade connector.
The tab thickness is 0.032 inches.
