KEMET R41-T Polypropylene Capacitor Y2, 10% Tolerance, 680 nF, 300V DC, 300V AC, Through Hole R413R368050T0K

Free Delivery in India | Lowest Global Shipping Charges

KEMET R41-T Polypropylene Capacitor Y2, 10% Tolerance, 680 nF, 300V DC, 300V AC, Through Hole R413R368050T0K

Name: KEMET R41-T Polypropylene Capacitor Y2, 10% Tolerance, 680 nF, 300V DC, 300V AC, Through Hole R413R368050T0K
Brand: KEMET
SKU: 166081
Price: 3.5 USD
Availability: InStock



Category Film Capacitors Brand KEMET Condition New

Specifications

Country of Origin	China
Brand	KEMET
Height	33mm
Length	32mm
Model	R413R368050T0K
Packaging	Bag
Width	18mm
Mount Type	Through Hole
Series	R41-T
Maximum Operating Temperature	125°C
Tolerance	10 %
Capacitance	680nF
Minimum Operating Temperature	-40°C
Dissipation Factor	0.3%
Lead Length	25mm
Standards/Approvals	UL, CAN, CSA, EN, IEC
Pin Count	2
Rated AC Voltage	300V ac
Rated DC Voltage	300V dc
Lead Pitch	27.5mm
Lead Diameter	0.8mm
Automotive Standard	AEC-Q200
Suppression Class	Y2

Key Features

Constructed with metallized polypropylene film encapsulated in self-extinguishing resin meeting UL 94 V-0 standards.
Designed for electromagnetic interface suppression in line-to-ground and across-the-line applications.
Operating temperature range from -40°C to +125°C ensures robust performance.
Lead pitch of 27.5 mm and 0.8 mm lead diameter for reliable PCB mounting.
Compliant with automotive standard AEC-Q200 and multiple international approvals including UL, CAN, CSA, EN, and IEC.
Dissipation factor of 0.3% reduces power losses in electronic circuits.
Pin count of 2 pins makes it compatible with various circuit designs.
Lead length of 25 mm provides secure soldering capability.

Product Description

KEMET R413R368050T0K Polypropylene Capacitor Y2 is a high-quality passive electronic component designed with metallized polypropylene film and self-extinguishing resin encapsulation compliant with UL 94 V-0. This capacitor offers a capacitance of 680 nF with a 10% tolerance, rated for 300V DC and 300V AC, making it ideal for EMI suppression in electromagnetic interface applications including line-to-ground and across-the-line filtering.

With an operating temperature range from -40°C up to 125°C, it ensures durability and stable performance in harsh conditions. Its lead pitch of 27.5mm and lead diameter of 0.8mm are suited for through-hole mounting onto printed circuit boards, and a pin count of 2 supports a variety of circuit configurations.

The capacitor conforms to the automotive standard AEC-Q200 and holds multiple certifications such as UL, CAN, CSA, EN, and IEC standards, underscoring its high reliability and safety compliance.

Additional features include a dissipation factor of 0.3%, which minimizes energy loss and improves circuit efficiency. The compact dimensions of 33mm height, 32mm length, and 18mm width allow easy integration into electronic assemblies, while the lead length of 25mm facilitates soldering.

This polypropylene capacitor is supplied in convenient bag packaging, appropriate for industrial and laboratory use. It is widely applicable in electromagnetic interference filtering, power electronics, and automotive electronics.

Constructed with metallized polypropylene film encapsulated in flame retardant resin. Rated for 300V DC and 300V AC applications with 10% capacitance tolerance. Automotive standard AEC-Q200 compliant and certified under multiple international standards.

Operating temperatures from -40°C to +125°C for reliable performance. Pin count of two with through-hole lead pitch of 27.5 mm. Dissipation factor of 0.3% for energy efficiency. Compact dimensions for versatile mounting options.

Ideal for EMI suppression in industrial, automotive, and electronic equipment. Supplied in bag packaging for ease of use and storage. Explore more electronic components and Film Capacitors through EnvMart for advanced industrial and laboratory applications.
