Wurth Elektronik WR-WTB Series Vertical Surface Mount PCB Socket, 8-Contact, 1 Row, 1 Pitch, 500V, 3A 665308124022

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WR-WTB Series Vertical Surface Mount PCB Socket, 8-Contact, 1 Row, 1 Pitch, 500V, 3A 665308124022

Name: Wurth Elektronik WR-WTB Series Vertical Surface Mount PCB Socket, 8-Contact, 1 Row, 1 Pitch, 500V, 3A 665308124022
Brand: Wurth Elektronik
SKU: 165388
Price: 1.65 USD
Availability: InStock



Category PCB Sockets Brand Wurth Elektronik Condition New

Specifications

Country of Origin	India
Voltage	500V
Brand	Wurth Elektronik
Orientation	Vertical
Current	3A
Mount Type	Surface
Housing Material	Polybutylene Terephthalate
Contact Material	Copper Alloy
Series	WR-WTB
Termination Type	Surface Mount
Maximum Operating Temperature	105°C
Sub Type	SMT Male Vertical Shrouded Header
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	1
Contact Plating	Gold
Number of Contacts	8
Contact Gender	Female
Connector System	Board-to-Board
Row Pitch	2.54mm

Key Features

Constructed with a beige UL94-V0 rated Polybutylene Terephthalate insulator for enhanced safety.
Supports operating voltage up to 500V and current rating of 3A.
Contacts are gold plated copper alloy for excellent conductivity and corrosion resistance.
Designed for vertical surface mounting with a row pitch of 2.54mm.
Operates reliably in temperature ranges from -40°C to +105°C.
Suitable for electronic assembly applications requiring durable SMT male vertical shrouded headers.
Ensures female contact gender configuration for secure mating with male connectors.
Ideal for industrial, laboratory, and electronic manufacturing environments.

Product Description

Wurth Elektronik 665308124022 is a high-quality vertical surface mount PCB socket from the WR-WTB series, featuring 8 female contacts arranged in a single row with 1mm pitch. This SMT male vertical shrouded header provides secure, board-to-board connectivity designed specifically for surface mounting applications.

The socket is constructed using a beige Polybutylene Terephthalate housing material that meets the UL94 V-0 flammability rating, ensuring enhanced fire safety compliance. Its stamped tin plated phosphor bronze contacts are plated with gold, offering superior electrical conductivity as well as corrosion resistance.

This connector supports a current rating of 3A and can handle voltages up to 500V, making it suitable for a wide range of power and signal transmission applications in demanding electronics projects. The vertical orientation with a row pitch of 2.54mm enables compact, reliable connections in circuit board assemblies.

Designed to operate in harsh environments, the WR-WTB socket withstands temperatures from -40°C to 105°C, ensuring durability and performance stability under industrial and laboratory conditions.

Applications for this socket include electronic component assemblies, power and connector distribution in industrial equipment, laboratory instrumentation, and general electronics manufacturing.

Beige UL94 V-0 rated PBT housing ensures safety and durability. Gold plated copper alloy contacts provide reliable conductivity. Supports 3A current and 500V voltage ratings. Compact 8-contact design with 1 row and 1mm pitch for versatile use.

Operating temperature range from -40°C to +105°C for hard environments. Explore Wurth Elektronik products and related PCB socket solutions on EnvMart for professional-grade electronic components and connectors.
