ROLEC Conform Series Die Cast Aluminium Enclosure IP66 IP67 90 mm x 225.5 mm x 125.5 mm IP66

ROLEC IP66 Die Cast Aluminium Enclosure from the Conform Series provides a highly robust, versatile solution for protecting electronic components in industrial and commercial settings. The enclosure features a baked enamel finish on heavy-duty die cast aluminium housing and a grey lid with matching color, ensuring durability and corrosion resistance.

The enclosure meets IP66 and IP67 ingress protection ratings, rendering it dustproof and resistant to powerful water jets and temporary immersion, making it suitable for harsh environmental conditions. Its built-in RFI shielding offers superior protection against electromagnetic interference, critical for sensitive electronic instrumentation.

The design includes a unique overlapping tongue and groove and tooth system between lid and base to guarantee continuous contact and sealing integrity. Internally, threaded screw bosses are provided for the secure fitting of PCBs and other board types, accompanied by copper-plated screws and earth tags, facilitating reliable grounding.

A neoprene sealing gasket further ensures environmental protection while the lid fixing screws and mounting holes are positioned outside the gasket area to allow easy access for servicing. This enclosure operates effectively within a wide temperature range of -40°C to +80°C.

Applications include test and measurement instrumentation, medical devices, transportation equipment, industrial controls, and lighting applications, making this a flexible choice for diverse industries requiring secure electronic enclosures.

Constructed from durable die cast aluminium for excellent protection and longevity. IP66 and IP67 rated for dust tightness and water immersion resistance. Integrated RFI shielding with baked enamel finish ensures electrical interference protection.

Grey lid and body with tooth system for continuous contact and secure sealing. Pre-threaded screw bosses inside for mounting boards securely. Neoprene sealing gasket provides additional environmental protection. Temperature range from -40°C to +80°C suitable for diverse industrial applications.

Includes captive lid fixing screws, external to gasket area for maintenance ease. Designed for industrial controls, instrumentation, medical devices, and lighting applications. Made in Germany ensuring high quality and manufacturing standards.
