ABB Residual Current Circuit Breaker with Overload Protection, 10A Current Rating, 2-Pole 2CSR255080R3104 DS201 C10 AC300



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	India
Range	System Pro M Compact
Brand	ABB
Height	85mm
Model	2CSR255080R3104 DS201 C10 AC300
Depth	69mm
Width	35mm
Mount Type	DIN Rail
Current Rating	10A
Series	DS201
Terminal type	Screw
Breaking Capacity	6kA
Number of Poles	2
Standards/Approvals	IEC, RoHS
Rated AC Voltage	230V ac
Tripping Characteristics	Type C
Tripping Mechanism	Thermal Magnetic
Trip Sensitivity	300mA
Earth Leakage Protection Type	AC

Key Features

Equipped with thermal magnetic tripping mechanism for overload and short-circuit protection.
Designed for single-phase circuits with DIN rail mount compatibility.
Features screw terminal type ensuring secure and reliable connections.
Offers AC type earth leakage protection for sinusoidal alternating fault currents.
Compact dimensions of 85mm height, 69mm depth, and 35mm width optimize panel space usage.
Breaking capacity of 6kA ensures safety under fault conditions.
Conforms to IEC and RoHS standards for quality and environmental compliance.

Product Description

ABB 2CSR255080R3104 DS201 C10 AC300 Residual Current Circuit Breaker with Overload Protection is designed for effective and safe management of single-phase electrical circuits. Rated for 10A current and featuring two poles, this device provides reliable protection against overloads, short circuits, and earth leakages with 300 mA trip sensitivity. It uses a type C thermal magnetic tripping mechanism suitable for residential and commercial environments.

This circuit breaker is part of the DS201 series within the System Pro M Compact range and is intended for DIN rail mounting, facilitating easy integration into electrical panels. Its screw terminal type connections support solid and secure wiring installations.

Operating at a rated AC voltage of 230V, it offers earth leakage protection specifically against sinusoidal alternating fault currents (AC type). The device dimensions include a height of 85mm, depth of 69mm, and width of 35mm, making it compact and space-efficient.

The breaker has a breaking capacity of 6kA, which ensures safety and protection under short-circuit conditions. It is compliant with international IEC standards and RoHS requirements, affirming its reliability and environmental safety.

Equipped with thermal magnetic tripping mechanism for overload and short-circuit protection. Designed for single-phase circuits with DIN rail mount compatibility. Rated voltage of 230V AC suitable for standard electrical installations.

Features screw terminal type ensuring secure and reliable connections. Offers AC type earth leakage protection for sinusoidal alternating fault currents. Compact dimensions of 85mm height, 69mm depth, and 35mm width optimize panel space usage.

Breaking capacity of 6kA ensures safety under fault conditions. Conforms to IEC and RoHS standards for quality and environmental compliance.

Ideal for residential, commercial, and light industrial applications, this ABB Residual Current Circuit Breaker ensures electrical circuit safety and protection against faults. Its reliable technology supports electrical safety in a variety of environments, including home automation and electrical distribution systems.
