RS PRO 6 Pole Straight Standard DIN Plug 100V AC 4A Cable Male 491-150

Free Delivery in India | Lowest Global Shipping Charges

RS PRO 6 Pole Straight Standard DIN Plug 100V AC 4A Cable Male 491-150

Name: RS PRO 6 Pole Straight Standard DIN Plug 100V AC 4A Cable Male 491-150
Brand: RS PRO
SKU: 163146
Price: 3.71 USD
Availability: InStock



Category DIN Plug Brand RS PRO Condition New

Specifications

Country of Origin	Taiwan
Voltage	100V ac
Brand	RS PRO
Orientation	Straight
Current	4A
Model	491-150
Mount Type	Cable
Housing Material	ABS
Contact Material	Brass
Series	RS PRO
Insulation resistance	100MΩ at 500V DC min
Rating	100V AC 4A max
Voltage Withstand	250V AC for 1 minute
Shield Type	Shielded
Contact Resistance	Pins 30mΩ max. Shell 50mΩ max
Pole Format	6
Contact Plating	Silver
Number of Contacts	6
Contact Gender	Male
Connector Gender	Male
Connector Size	Standard
Set screw and 'T' holder	Steel Nickel Plated
RS PRO 6 Pole Din, 2A, 34 V ac/dc, Male, Cable MountBrand	RS PRO
RND, RND 6 Pole Straight DIN Connector, 4A, 125V, Threaded, Panel MountBrand	RND

Key Features

This DIN plug features 6 contact poles optimized for reliable signal transmission.
The connector is shielded and made with ABS housing for durability.
Silver-plated brass contacts provide low resistance and corrosion protection.
The straight orientation and cable mount type simplify installation.
Rated to withstand up to 250V AC for 1 minute for robust use.
Contact resistance ratings of maximum 30mΩ on pins and 50mΩ on the shell ensure performance.
Insulation resistance of 100MΩ at 500V DC minimizes electrical leakage.
Ideal for industrial, audio, computing and power connection applications.

Product Description

RS PRO model 491-150 is a 6 pole straight standard DIN plug designed for cable mounting with male contacts. It operates at a voltage rating of 100V AC and a current capacity of 4A, making it suitable for a variety of electronic and electrical applications.

The plug features a robust ABS housing with a nickel-plated zinc alloy shield cover for mechanical strength and shielding against electromagnetic interference. Silver-plated brass contacts ensure reliable conductivity and resistance to corrosion, maintaining signal integrity.

The connector is shielded and uses a set screw and 'T' holder made from steel nickel plated, enhancing the durability and secure fit of the connector assembly. The straight orientation with cable mount design facilitates easy and secure cable connection in industrial setups.

Performance ratings include contact resistance with pins at 30 milliohms maximum and the shell rated at 50 milliohms maximum. It also offers insulation resistance up to 100 megaohms at 500V DC and voltage withstand capability of 250V AC for 1 minute, ensuring safety and reliability in operation.

DIN connectors like this are commonly used in industrial automation, audio equipment, computing interfaces, and power supply connections, providing secure, high-quality connections. RS PRO supplies a broad range of DIN connectors with similar robust features ensuring compatibility and quality.

This DIN Plug features 6 contact poles optimized for reliable signal transmission. The connector is shielded and made with ABS housing for durability. Silver-plated brass contacts provide low resistance and corrosion protection.

The straight orientation and cable mount type simplify installation. Rated to withstand up to 250V AC for 1 minute for robust use. Contact resistance ratings of maximum 30mΩ on pins and 50mΩ on the shell ensure performance.

Insulation resistance of 100MΩ at 500V DC minimizes electrical leakage. Ideal for industrial, audio, computing and power connection applications. Explore the comprehensive RS PRO range of DIN connectors for all your professional electrical and electronic connectivity needs.
