Phoenix Contact Horizontal Surface PCB Socket 16-Contact 2 Row 1.27 mm Pitch 500 V 1.4 A FP 1.27/ 16-FH 1714871

Free Delivery in India | Lowest Global Shipping Charges

Phoenix Contact Horizontal Surface PCB Socket 16-Contact 2 Row 1.27 mm Pitch 500 V 1.4 A FP 1.27/ 16-FH 1714871

Name: Phoenix Contact Horizontal Surface PCB Socket 16-Contact 2 Row 1.27 mm Pitch 500 V 1.4 A FP 1.27/ 16-FH 1714871
Brand: PHOENIX CONTACT
SKU: 161650
Price: 5.45 USD
Availability: InStock



Category PCB Socket Brand PHOENIX CONTACT Condition New

Specifications

Country of Origin	Czech Republic
Voltage	500V
Brand	Phoenix Contact
Orientation	Horizontal
Current	1.4A
Model	1714871
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Copper
Series	FP 1.27/ 16-FH
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	Female Connector
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	1.27mm
Contact Plating	Gold
Number of Contacts	16
Contact Gender	Female
Connector System	Board-to-Board
Stacking Height	8mm
SMD female connector, Nominal current at 20 °C	1.4 A, Test voltage: 500 V AC, number of positions: 16, pitch: 1.27 mm, colour: black, contact surface: Gold, mounting: SMD soldering
Phoenix Contact FR Connector Set Containing SMD Female ConnectorsBrand	Phoenix Contact

Key Features

This connector features 16 contacts arranged in 2 rows with a 1.27 mm pitch.
Mount type is surface-mount suitable for horizontal orientation on PCBs.
The connector housing is made from durable Liquid Crystal Polymer.
Contacts are copper with gold plating ensuring reliable electrical connection.
Rated for a nominal current of 1.4 A and a test voltage of 500 V AC.
Operating temperature ranges from -55°C to 125°C for demanding environmental conditions.
Stacking height of 8 mm allowing compact PCB stacking.
Designed as an SMD female connector for solder termination.

Product Description

Phoenix Contact 1714871 is a Horizontal Surface PCB Socket specifically designed for electronic and electrical assemblies requiring board-to-board female connections.

This 16-contact, 2-row connector features a precise 1.27 mm pitch and is made with a housing of Liquid Crystal Polymer, ensuring robustness and stability in demanding industrial environments.

Its contacts are composed of copper with gold plating for superior conductivity and corrosion resistance, rated for a nominal current of 1.4 A and a test voltage of 500 V AC, making it suitable for medium-power PCB applications.

The connector supports surface mounting with solder termination and is horizontally oriented to facilitate compact PCB stacking with an 8 mm stacking height. Operating temperature is rated from -55°C to 125°C, enabling use in a wide range of industrial, commercial, and electronic manufacturing environments.

This connector has 16 contacts distributed in 2 rows at a 1.27 mm pitch. Its housing material is durable Liquid Crystal Polymer. Contacts are female copper plated with gold for reliability. Mounts using SMD soldering on horizontal PCBs.

Operates safely up to 1.4 A nominal current and 500 V test voltage AC.

Perfect for industrial electronics manufacturing, PCB assembly, power distribution, and signal connections, the Phoenix Contact FP 1.27/ 16-FH Series ensures robust, reliable surface PCB connections with high-density contact packaging.
