Microchip 8-bit AVR Microcontroller 16kB FLASH 20 MHz 48-Pin UQFN ATMEGA1609-MF

The Microchip ATMEGA1609-MF is a high-performance 8-bit AVR microcontroller designed for industrial and commercial electronic applications. Featuring a 20 MHz clock speed and a 16 kB FLASH program memory, it provides reliable and efficient processing capabilities for embedded systems. The device employs a RISC-based instruction set, optimizing power consumption and execution speed.

With 2 kB of SRAM and 256 bytes of EEPROM, the microcontroller supports robust data storage and retrieval essential for complex algorithms and stateful applications. Its operating voltage ranges from 1.8 V to 5.5 V, allowing integration in diverse power environments. The 48-pin UQFN package supports surface mount assembly, enabling compact PCB designs with a small footprint measuring 6 mm by 6 mm and a height of 900 µm.

The microcontroller includes 41 programmable input/output pins, facilitating control of multiple peripherals and interfaces. It features 16 channels of 10-bit analog-to-digital converters (ADCs) ideal for precise sensor measurements. Five versatile timers provide timing and pulse-width modulation options, while a single analogue comparator enhances signal processing capabilities.

Designed to operate in harsh industrial environments, the ATMEGA1609-MF functions reliably across a wide temperature range from -40°C to 125°C. Power dissipation is limited to 1 watt, promoting energy efficiency in embedded systems. Compliance with RoHS directives ensures the product meets environmental and safety standards.

This microcontroller is suited for applications in industrial automation, automotive systems, consumer electronics, and embedded control systems requiring a compact yet powerful processing unit. The advanced peripheral set, including the event system and hardware multiplier, supports innovative user designs.

Equipped with 2 kB SRAM and 256 bytes EEPROM for data management. Wide operating voltage range from 1.8 V to 5.5 V. Compact 48-pin UQFN surface mount package. Supports up to 20 MHz clock frequency for fast processing. 41 Programmable I/O pins and 16 channel 10-bit ADCs.

Five timers for various timing requirements. Industrial temperature range from -40°C to 125°C. Low power dissipation at 1 W. RISC architecture with hardware multiplier for efficient computation. Compliant with RoHS environmental standards.
