HARTING DIN 41612 Connector 160 Contacts 5 Row 2.54 mm Pitch Through Hole Female Press-in Termination Class C1 02021601301

Free Delivery in India | Lowest Global Shipping Charges

HARTING DIN 41612 Connector 160 Contacts 5 Row 2.54 mm Pitch Through Hole Female Press-in Termination Class C1 02021601301

Name: HARTING DIN 41612 Connector 160 Contacts 5 Row 2.54 mm Pitch Through Hole Female Press-in Termination Class C1 02021601301
Brand: HARTING
SKU: 160473
Price: 51.12 USD
Availability: InStock



Category DIN 41612 Connectors Brand HARTING Condition New

Specifications

Country of Origin	Germany
Brand	HARTING
Orientation	Straight
Current	1A
Mount Type	Through Hole
Housing Material	Liquid Crystal Polymer
Contact Material	Copper Alloy
Series	har-bus 64
Termination Type	Press-in
Maximum Operating Temperature	125°C
Sub Type	har-bus 64
Minimum Operating Temperature	-55°C
Number of Rows	5
Pitch	2.54mm
Contact Plating	Gold over Nickel
Number of Contacts	160
Contact Gender	Female
Connector Gender	Female
Maximum Contact Resistance	30mΩ
Row Loading	A, D, Z, C, B

Key Features

Designed for through hole mounting with female connector gender.
Features press-in termination ensuring secure and reliable connection.
Contact plating is gold over nickel for enhanced conductivity and corrosion resistance.
Operates within -55°C to 125°C temperature range for industrial applications.
Class C1 rated to meet IEC 61076-4-113 standards with a maximum contact resistance of 30 mΩ.
Connector body made from liquid crystal polymer for durability and stability.
Suitable for use in electronic component integration, backplane and rack connectors.
Supports current up to 1 Ampere and includes five rows loaded in A, D, Z, C, B configurations.

Product Description

HARTING 02021601301 DIN 41612 connector provides a high-quality backplane signal connection with 160 contacts arranged in 5 rows, featuring a 2.54 mm pitch. Its through hole mounting style and press-in termination offer easy assembly and robust mechanical stability, ideal for VME64 and other industrial electronic applications.

The female connector design with gold over nickel plating on copper alloy contacts ensures excellent conductivity and resistance to wear over long term use. Constructed from liquid crystal polymer, this connector supports a wide operating temperature range from -55°C to 125°C, suitable for various demanding environments.

Designed to meet Class C1 standards under IEC 61076-4-113, it guarantees compatibility and reliable performance in Eurocard racking systems. Through hole mounting style with press-in termination for secure connections. Gold over nickel contact plating enhances electrical conductivity and corrosion resistance.

Capable of handling currents up to 1 Ampere with a maximum contact resistance of 30 mΩ. Robust liquid crystal polymer housing resists mechanical and thermal stress. Compatible with existing DIN 41612 Type C connectors ensuring backward and forward compatibility.

Five-row configuration maximizes contact density for high pin count applications. Suitable for industrial, laboratory, manufacturing, and commercial electronic interconnect applications. This connector is a part of the HARTING har-bus 64 series known for high data transfer rates and reliable signal integrity.
