Osram Constant Current LED Driver 22W, 10-38V Output Voltage, 120mA, 220-240V Input, IP20, OPTOTRONIC NFC Series IP20

Free Delivery in India | Lowest Global Shipping Charges

Osram Constant Current LED Driver 22W, 10-38V Output Voltage, 120mA, 220-240V Input, IP20, OPTOTRONIC NFC Series IP20

Name: Osram Constant Current LED Driver 22W, 10-38V Output Voltage, 120mA, 220-240V Input, IP20, OPTOTRONIC NFC Series IP20
Brand: Osram
SKU: 156036



Category LED Driver Brand Osram Condition New

Specifications

Country of Origin	India
Brand	Osram
Model	IP20
IP Rating	IP20
Mount Type	Screw
Series	OPTOTRONIC NFC
Configuration	Enclosed
Sub Type	LED Driver
Operating Modes	Constant Current
Number of outputs	1
Terminal type	Push-in
Maximum Output Power	22W
Input Voltage	220, 240V
Output Voltage	10, 38V
Power Dissipation	3.5W
Standards/Approvals	CCC, EN, CQC, CE, VDE, UL, IEC, ENEC
Dimming Operation	1DIM
Primary Type	AC-DC
Driver Current	120mA
LED Voltage	240V

Key Features

Designed for constant current operation to ensure stable LED performance.
Input voltage range from 220 to 240 volts AC.
Equipped with 1DIM dimming for versatile light control.
IP20 rated for indoor installation with screw mounting.
Includes push-in terminal for easy wiring connections.
Wide operating temperature range from -40°C to 60°C.
Compliant with multiple international standards including CCC, EN, CQC, CE, VDE, UL, IEC, and ENEC.
Features low power dissipation of 3.5W for energy efficiency.

Product Description

Osram IP20 model LED driver is a high-quality constant current driver designed to power LED lighting with a maximum output power of 22 watts. It features a flexible output voltage range from 10 to 38 volts and delivers a constant current of 120mA. The device supports a nominal supply input voltage of 220 to 240 volts AC and provides efficient power management with only 3.5 watts of power dissipation. Ideal for industrial and commercial LED lighting applications, it supports 1DIM dimming for precise light level adjustments.

This LED driver is mounted via screws and features push-in terminals for secure electrical connections. It is enclosed with an IP20 rating, making it suitable for use in protected indoor environments. The device includes advanced features such as AstroDIM for autonomous dimming and integrated thermal management using driver guard technology. Its wide temperature tolerance from -40°C up to 60°C ensures reliable operation in varied conditions.

Osram's OPTOTRONIC NFC series, including this IP20 model, complies with numerous safety and quality standards including CCC, EN, CQC, CE, VDE, UL, IEC, and ENEC certifications, ensuring reliable and safe usage. It is designed for industrial, commercial, and street lighting deployments requiring stable and efficient LED current supply with dimming capability.

Constant current operation guarantees consistent LED brightness. Wide voltage and temperature ranges provide installation flexibility. AstroDIM function offers autonomous dimming with five selectable levels. Wireless luminaire programming via NFC enables fast setup and adjustments.

Integrated thermal protection helps prevent overheating and extends service life. Compliant with major international standards ensuring safety and reliability. Designed for use in indoor luminaires meeting IP20 protection standard.

This product is an excellent choice for applications within industrial, commercial, and architectural lighting sectors. For further lighting solutions, browse LED Drivers in EnvMart’s Electronics Components category.
