Schneider Electric ComPact Compact NSXm Molded Case Circuit Breaker 3-Pole 25A 690V AC 70kA Thermal Magnetic LV426551
Specifications
| Country of Origin | India |
|---|---|
| Range | ComPact |
| Brand | Schneider Electric |
| Height | 137mm |
| Model | LV426551 |
| Depth | 80mm |
| Width | 137mm |
| Mount Type | Clip-on |
| Current Rating | 25A |
| Series | Compact NSXm |
| Terminal type | Screw |
| Breaking Capacity | 70kA |
| Number of Poles | 3 |
| Standards/Approvals | CCC, CE, EAC, EN, IEC, RoHS |
| Rated AC Voltage | 690V ac |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Thermal Magnetic |
| Reset Actuator Type | Toggle Switch |
Key Features
- Compact NSXm series designed for industrial electrical installations.
- Thermal magnetic tripping mechanism ensures precise overload and short circuit protection.
- Type D tripping characteristics suited for motor protection.
- Mounting type is clip-on for easy installation.
- Toggle switch reset actuator for manual control.
- Screw terminal type ensures secure and stable connections.
- Complies with CCC, CE, EAC, EN, IEC, and RoHS standards.
- Designed for rated AC voltage of 690V for heavy-duty applications.
Product Description
Schneider Electric LV426551 is a high-performance molded case circuit breaker from the ComPact Compact NSXm series, offering 3-pole switching at 25A with a breaking capacity of 70kA at 690V AC. This circuit breaker is engineered for reliable electrical system protection in industrial, commercial, and manufacturing environments.
The device features a thermal magnetic tripping mechanism with Type D characteristics, which provides superior protection against overload and short circuits, particularly for motors and inductive loads. Its clip-on mounting facilitates easy installation in equipment panels, while the toggle switch actuator allows for quick manual resetting.
Screw terminals ensure robust and secure electrical connections, enabling enhanced durability and safety during operation. The compact dimensions of 137mm height, 137mm width, and 80mm depth allow for efficient space utilization in electrical enclosures.
This circuit breaker complies with stringent quality and safety standards, including CCC, CE, EAC, EN, IEC, and RoHS, making it suitable for global industrial electrical installations.
Compact NSXm series designed for industrial electrical installations. Thermal magnetic trip mechanism ensures precise overload and short circuit protection. Type D trip characteristics geared for motor protection applications.
Clip-on mount type enables quick and secure installation. Toggle switch actuator for manual reset operation. Screw terminals provide stable and easy wiring connection. Compact form factor dimensions of 137mm (H) x 137mm (W) x 80mm (D).
Conforms to international safety and environmental standards.
This molded case circuit breaker is ideal for electrical distribution, industrial plants, motor control centers, HVAC systems, and manufacturing setups requiring reliable circuit protection at 690V AC and 25A current rating.
Explore more Schneider Electric Circuit Breakers and electrical components in the Electronics & Electricals category at EnvMart for trusted industry solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The breaking capacity of this molded case circuit breaker is 70kA at 690V AC.
This model has dimensions of 137mm in height, 137mm in width, and 80mm in depth.
The current rating for this unit is 25A.
It features a thermal magnetic tripping mechanism.
The tripping characteristics are Type D, which are suited for motor protection applications.
It is designed for clip-on mounting, allowing for easy installation.
This model utilizes screw terminals for secure and stable connections.
It complies with CCC, CE, EAC, EN, IEC, and RoHS standards.
It belongs to the ComPact NSXm series, designed for industrial electrical installations.
It is suitable for electrical distribution, industrial plants, motor control centers, HVAC systems, and manufacturing setups.
The rated AC voltage for this model is 690V.
The reset actuator type is a toggle switch, allowing for manual control.
