Hongfa Europe GMBH PCB Power Relay 12V DC Coil 20A Switching Current SPDT HF14FW/012-ZSPTF
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 26.5mm |
| Length | 29mm |
| Model | HF14FW/012-ZSPTF |
| Width | 13mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF14FW |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 20A |
| Terminal type | PCB Pin |
| Contact Resistance | 50mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 275Ω |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 277V |
| Coil Power | 720mW |
Key Features
- Operates with a 12V DC coil and supports switching currents up to 20A.
- Features 1 Form C (SPDT) silver alloy contacts ensuring reliable connection.
- Suitable for high power switching up to 5.5 kVA AC and 30V DC switching voltage.
- Operating temperature range from -40°C to 85°C enables usage in diverse environments.
- Compact dimensions of 29mm length, 13mm width, and 26.5mm height for easy PCB integration.
- Coil resistance of 275 ohms and coil power consumption of 720mW.
- Plastic sealed construction provides environmental protection and durability.
- RoHS compliant, eco-friendly product suitable for automotive and industrial control applications.
Product Description
Hongfa Europe GMBH HF14FW/012-ZSPTF PCB Power Relay is a high-performance non-latching electromagnetic relay designed for printed circuit board mounting. It operates with a 12V DC coil and can handle switching currents of up to 20A, making it suitable for medium power control applications.
This SPDT (1 Form C) relay features silver alloy contacts that provide low resistance and high reliability. Its switching power rating is 5.5 kVA AC and it supports switching voltages up to 277V AC and 30V DC, making it versatile for various electronic circuits.
The relay is designed for robust operation in a temperature range from -40°C to 85°C, suitable for demanding industrial and automotive environments. Its compact size of 29mm length, 13mm width, and 26.5mm height allows for efficient PCB space utilization.
The coil has a resistance of 275 ohms and consumes 720 mW power, ensuring efficient electromagnetic actuation. The relay housing is plastic sealed to protect internal components from environmental exposure, increasing longevity and reliability.
Additional advantages include a high isolation voltage of 4 kV AC between coil and contacts, ensuring safety in electrical operations. The product is RoHS compliant, making it an environmentally responsible choice for electronics manufacturers.
This relay is ideal for use in industrial automation systems, automotive controls, and electronic manufacturing where reliable switching and compact size are required. It can be used as a control device for switching high currents in various electrical circuits.
Operates with a 12V DC coil and supports switching currents up to 20A. Features 1 Form C (SPDT) silver alloy contacts ensuring reliable connection. Suitable for high power switching up to 5.5 kVA AC and 30V DC switching voltage.
Operating temperature range from -40°C to 85°C enables usage in diverse environments. Compact dimensions of 29mm length, 13mm width, and 26.5mm height for easy PCB integration. Coil resistance of 275 ohms and coil power consumption of 720mW.
Plastic sealed construction provides environmental protection and durability. RoHS compliant, eco-friendly product suitable for automotive and industrial control applications. Isolation voltage between coil and contacts is 4KV AC for safety and reliability.
Ideal for use as a control device in industrial, automotive, and electronic manufacturing applications. Explore more Power Relays from the Hongfa Europe GMBH brand and other industrial electrical components at EnvMart for your automation and electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports switching currents up to 20A.
It operates with a 12V DC coil voltage.
The relay can switch voltages up to 277V AC and 30V DC.
The relay has compact dimensions of 29mm in length, 13mm in width, and 26.5mm in height.
It operates effectively within a temperature range from -40°C to 85°C.
It features 1 Form C (SPDT) silver alloy contacts, ensuring reliable connection.
The coil resistance is 275 ohms.
The coil power consumption is 720mW.
The isolation voltage is 4 kV AC, ensuring safety in electrical operations.
Yes, the product is RoHS compliant, making it an environmentally responsible choice.
This model is designed for PCB mounting.
It is suitable for industrial automation systems, automotive controls, and electronic manufacturing applications.
