ABB Residual Current Circuit Breaker with Overload Protection, 6A Current Rating 2CSR275051R1064 DSE201 M C6 AC30 - N Blue



Category Residual Current Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	India
Range	System Pro M Compact
Brand	ABB
Height	115mm
Model	2CSR275051R1064 DSE201 M C6 AC30 - N Blue
Depth	69mm
Width	18mm
Mount Type	DIN Rail
Current Rating	6A
Series	DSE201 M
Terminal type	Screw
Breaking Capacity	10kA
Number of Poles	1
Standards/Approvals	IEC, RoHS
Rated AC Voltage	240V ac
Tripping Characteristics	Type C
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Toggle Switch
Trip Sensitivity	30mA
Earth Leakage Protection Type	AC
RCBO's	DIN rail mounting with an operating temperature range of -25 to +55 °C. Optimum frequency range of 50 to 60Hz

Key Features

Offers protection against short circuit currents, overloads, and earth fault currents.
Equipped with thermal magnetic tripping mechanism ensuring reliable overcurrent protection.
Type C tripping characteristic suitable for general applications.
Mounts easily on DIN rail for convenient installation.
Designed with toggle switch reset actuator for manual operation.
Rated for 240V AC voltage with screw terminal connections.
Compact size with dimensions 115mm height, 69mm depth, and 18mm width.
Breaking capacity of 10kA ensures high fault current tolerance.

Product Description

ABB 2CSR275051R1064 DSE201 M C6 AC30 - N Blue Residual Current Circuit Breaker with overload protection is designed for reliable electrical safety in industrial, commercial, and residential electrical systems. This 1-pole device integrates residual current and overcurrent protection in one compact unit, suitable for DIN rail installation.

It provides protection against short circuit currents, overloads, earth fault currents, and indirect contact hazards. The device features a thermal magnetic type C tripping characteristic, enabling sensitive and robust circuit interruption under fault conditions.

Operating at a rated AC voltage of 240V, it supports a current rating of 6A and trip sensitivity of 30mA for earth leakage detection. The breaker has a breaking capacity of 10kA offering high fault tolerance to ensure circuit and personnel safety. Its screw terminal design facilitates secure wiring connections.

The device is built to standards IEC and RoHS, with a functional operating temperature range of -25 to +55 °C and supports frequency range 50 to 60Hz. Its physical dimensions are height 115mm, depth 69mm, width 18mm, making it compact for panel installations.

Applications include electrical power distribution boards, motor protection, and safety installations in commercial and industrial electrical setups. It is particularly suited for environments requiring earth leakage protection coupled with short circuit and overload safeguarding.

Offers protection against short circuit currents, overloads, and earth fault currents. Equipped with thermal magnetic tripping mechanism ensuring reliable overcurrent protection. Type C tripping characteristic suitable for general applications.

Mounts easily on DIN rail for convenient installation. Designed with toggle switch reset actuator for manual operation. Rated for 240V AC voltage with screw terminal connections. Compact size with dimensions 115mm height, 69mm depth, and 18mm width.

Breaking capacity of 10kA ensures high fault current tolerance. Applicable within temperature range of -25 to +55 °C and frequency of 50 to 60Hz. Explore ABB products and circuit breakers on EnvMart for high quality and durable electrical protection solutions.
