Microchip 8 bit PIC PIC16F1778-I/SP Microcontroller 32 MHz 28kB FLASH 28-Pin SPDIP PIC16F1778-I/SP
Specifications
| Country of Origin | India |
|---|---|
| Brand | Microchip |
| Height | 3.81mm |
| Length | 35.56mm |
| Model | PIC16F1778-I/SP |
| Width | 7.37mm |
| Mount Type | Through Hole |
| Series | PIC16 |
| Maximum Operating Temperature | 85°C |
| Package Type | SPDIP |
| Minimum Operating Temperature | -40°C |
| Ram size | 2kB |
| Interface Type | SPI, EUSART, I2C |
| Standards/Approvals | RoHS |
| Pin Count | 28 |
| Maximum Supply Voltage | 5.5V |
| Maximum Power Dissipation Pd | 800mW |
| Minimum Supply Voltage | 1.8V |
| Device Core | PIC |
| Program Memory Size | 28kB |
| Maximum Clock Frequency | 32MHz |
| Number of Programmable I/Os | 25 |
| Analogue Comparators | 2 |
| Number of Timers | 8 |
| Instruction Set Architecture | RISC |
| ADCs | 17 x 10 Bit |
| Program Memory Type | FLASH |
Key Features
- Supports multiple communications interfaces including SPI, EUSART, and I2C.
- Features an 8 MIPS max CPU speed with enhanced mid-range core architecture.
- Contains 25 programmable I/O pins for versatile integration.
- Includes 17 channels of 10-Bit ADC and 3 operational amplifiers.
- Operates within a supply voltage range of 1.8V to 5.5V with low power consumption features.
- Equipped with multiple digital peripherals such as PWMs, CCP modules, and configurable logic cells.
- Designed for applications including SMPS and embedded control requiring compact and efficient microcontrollers.
- Operating temperature range from -40°C to 85°C ensures robustness in diverse environments.
Product Description
Microchip PIC16F1778-I/SP is an 8 bit PIC microcontroller featuring a 32 MHz maximum clock frequency and 28kB of FLASH memory. It is packaged in a 28-pin SPDIP with a through-hole mount type, ideal for various electronic embedded applications.
This microcontroller implements Microchip's enhanced mid-range core with 49 instructions and 16 stack levels, supporting low current power-on reset and configurable power-up timers. It incorporates precision internal oscillators and various analog peripherals including 17 channels of 10-bit ADC, 2 analog comparators, digital-to-analog converters, operational amplifiers, and voltage reference modules.
The device includes digital peripherals such as enhanced USART, SPI, I2C communication interfaces, pulse-width modulators, and configurable logic cells supporting complex embedded control functions. Its 25 programmable I/Os enable flexible interfacing options. The microcontroller supports extended watchdog timers and low power features optimized for power-sensitive applications.
Designed for use in industrial, consumer electronics, and power management systems like SMPS, this MCU ensures high performance with power efficiency. It operates reliably between -40°C to 85°C, making it suitable for harsh conditions.
Supports SPI, EUSART, and I2C interfaces for versatile communication. High-speed internal oscillator and precision analog features. Multiple PWM channels and CCP modules for motor control and signal modulation. Robust power management with brown-out reset and power-up timer.
Complies with RoHS standards ensuring environmental safety. Compact 28-pin SPDIP packaging for ease of installation.
This microcontroller is an excellent choice for engineers and designers requiring reliable, low power, and feature-rich PIC MCUs. Explore more Microchip Microcontrollers on EnvMart for comprehensive solutions in embedded electronics.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum clock frequency of this microcontroller is 32 MHz.
It features a program memory size of 28kB, utilizing FLASH memory technology.
This microcontroller operates within a temperature range of -40°C to 85°C.
The PIC16F1778-I/SP includes 25 programmable I/O pins for versatile integration.
It supports multiple communication interfaces including SPI, EUSART, and I2C.
The minimum supply voltage is 1.8V, and the maximum supply voltage is 5.5V.
This microcontroller is packaged in a 28-pin SPDIP format with dimensions of 35.56mm in length, 7.37mm in width, and 3.81mm in height.
It includes 17 channels of 10-bit ADC and 2 analog comparators, enhancing its analog processing capabilities.
This model has 8 timers available for various timing applications.
The maximum power dissipation for this unit is 800mW.
The PIC16F1778-I/SP complies with RoHS standards, ensuring environmental safety.
It utilizes a RISC (Reduced Instruction Set Computing) architecture for its instruction set.
