TE Connectivity Panel Power Relay 12V dc Coil 30A Switching Current DPST T92S7D22-12 1-1393212-4
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Operating Temperature | -40°C to +65°C |
| Height | 30.7mm |
| Length | 52.3mm |
| Model | T92S7D22-12 1-1393212-4 |
| Width | 34.5mm |
| Mount Type | Panel |
| Contact Material | Silver Alloy |
| Series | T92 |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPST |
| Minimum Operating Temperature | -45°C |
| Switching Current | 30A |
| Terminal type | Quick Connect |
| Standards/Approvals | UR, UL, CSA |
| Coil Resistance | 96Ω |
| Coil Voltage | 12V dc |
| Switching AC Voltage | 600V ac |
| Coil Power | 1.7W |
| Switching Power | 1.7W |
Key Features
- Flange mount relay from T92 Series designed for reliable panel installation.
- Operates at a coil voltage of 12V dc with coil resistance of 96 ohms.
- Controls compressor loads up to 3.5 tons with 25.3 FLA rating.
- Rated for switching AC voltage up to 600V and switching power of 1.7W.
- Contact material is silver alloy ensuring excellent conductivity and durability.
- Features quick connect terminals for easy wiring and installation.
- Meets UL 873 and UL 508 standards with approvals from UL, CSA, and VDE.
- Operating temperature range from -40°C to +65°C, suitable for varied environments.
Product Description
TE Connectivity T92S7D22-12 1-1393212-4 Panel Power Relay is a flange mount relay from the T92 Series designed for reliable control of compressor and industrial load applications. Operating with a 12V dc coil voltage and a coil resistance of 96Ω, this relay efficiently switches currents up to 30A with a double pole single throw (DPST) contact configuration.
The relay meets stringent UL 873 and UL 508 spacing requirements, ensuring safe and compliant panel installation with a spacing of 8mm through air and 9.5mm over surface. It is built to handle compressor loads up to 3.5 tons with a full load amperage (FLA) of 25.3 and locked rotor amperage (LRA) of 110, making it suitable for HVAC and refrigeration industry control circuits.
Designed to switch AC voltages up to 600V and a switching power of 1.7W, the contact material is a durable silver alloy providing high conductivity and long-term reliability. Quick connect terminals facilitate fast and secure installation. The relay is UL recognized, CSA certified, and conforms to VDE standards, highlighting its compliance and quality assurance.
With an operating temperature range of -40°C to +65°C and UL class F construction, this relay is capable of performing reliably under harsh industrial and commercial conditions. Its compact dimensions (length 52.3mm, width 34.5mm, height 30.7mm) allow it to be mounted efficiently on panels.
This power relay is ideal for industrial automation, HVAC equipment control, electrical panels, and other commercial applications requiring robust switching capability. Its design ensures longevity and operational safety, meeting international standards required in industrial environments.
Flange mount panel design for easy installation. High current switching capability of 30A at 600V AC. Complies with UL, CSA, and VDE standards. Durable silver alloy contacts for reliable conductivity. Quick connect terminals for efficient wiring.
Wide operating temperature range suitable for various environments. Compact dimensions suitable for tight panel spaces. Designed for compressor load control and industrial applications. UL recognized and CSA certified ensuring quality and safety.
Conforms to multiple international electrical standards.
This product is categorized under Power Relays in the Electronics & Electricals sector and is highly recommended for professionals seeking reliable panel Power Relays from TE Connectivity.
Explore more electronic components and power relay solutions at EnvMart for your industrial and commercial project needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This relay has a maximum switching current capacity of 30A.
It operates at a coil voltage of 12V dc with a coil resistance of 96 ohms.
The relay features a double pole single throw (DPST) contact configuration.
It is rated for switching AC voltages up to 600V.
The dimensions of this relay are 52.3mm in length, 34.5mm in width, and 30.7mm in height.
The operating temperature range is from -40°C to +65°C.
The contact material is silver alloy, which ensures excellent conductivity.
It features quick connect terminals for easy wiring and installation.
It meets UL 873 and UL 508 standards and is recognized by UL, CSA, and VDE.
This relay is suitable for industrial automation, HVAC equipment control, and electrical panels.
The coil power rating is 1.7W.
The locked rotor amperage (LRA) rating is 110A, making it suitable for compressor load applications.
