Lumberg Minimodul Series Straight Through Hole PCB Header, 2 Contacts, 2.5 mm Pitch, 1 Row, Shrouded 2,5 MSF/O 02

Lumberg 2,5 MSF/O 02 Minimodul Series Straight Through Hole PCB Header features 2 contacts with a 2.5 mm pitch in a single-row, shrouded design. It is engineered for reliable wire-to-board connections using through-hole mounting for enhanced mechanical strength. This header mates specifically with 3114 Series crimp contact housings to provide secure cable-to-board interfaces.

Constructed with a glass filled polyamide housing, this connector offers high mechanical robustness and excellent thermal stability between -40°C and 120°C operating temperatures. The contacts are brass material coated with tin plating to ensure low contact resistance and corrosion resistance. The connector system supports currents up to 5 A, suitable for signal and low load applications in electronic assemblies.

The straight orientation and shrouded male contacts provide protection and alignment during mating. This component complies with DIN EN 60664/IEC 60664, IEC 60335-1, and IEC 60695-2-11 standards to meet international electrical and safety regulations. With compact 2.5 mm pitch and 1 row configuration, it enables space-efficient PCB layouts and flexible harnessing of single leads and flat cables.

These specifications make the Lumberg Minimodul header ideal for use in industrial, commercial electronic equipment, power connectors, control systems, and other precision electronics requiring reliable PCB interfacing solutions.

This PCB header is designed for wire-to-board cable connections using crimp contacts. It supports a current rating of up to 5 A suitable for signal and low load currents. The housing is made of durable glass filled polyamide for mechanical stability and heat resistance.

Features a straight orientation with shrouded male contacts plated in tin for reliable connectivity. Operates within a temperature range of -40°C to 120°C to withstand diverse environmental conditions. Conforms to DIN EN 60664/IEC 60664, IEC 60335-1 and IEC 60695-2-11 standards ensuring quality and safety.

The 2.5 mm pitch enables compact PCB layout and easy harnessing of single leads and flat cables. Ideal for industrial electronic components and power connector applications.
