HARTING SEK 18 Series Straight Through Hole Shrouded PCB Header 6 Contacts 2.54 mm Pitch 2 Row 09185066924
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 1kV |
| Brand | HARTING |
| Orientation | Straight |
| Current | 1A |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Copper Alloy |
| Series | SEK 18 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- The connector has a current rating of 1A suitable for low power applications.
- It is constructed with a polybutylene terephthalate housing for durable insulation.
- The contacts are made of copper alloy plated in gold for reliable conductivity and corrosion resistance.
- Designed for wire-to-board connection systems with through-hole mounting for mechanical stability.
- Operating temperature range is wide, from -55°C minimum to 125°C maximum, ensuring performance under varied conditions.
- The product voltage rating is 1 kV offering robust electrical insulation.
- Shrouded design provides enhanced protection against accidental contact and mechanical damage.
- Termination is via solder, with male contact gender to fit appropriate PCB sockets.
Product Description
HARTING 09185066924 PCB Header from the SEK 18 Series is a high-quality electronic component designed for reliable wire-to-board connections in industrial, commercial, and laboratory electronics applications.
The header features six male contacts arranged in two rows with 2.54 mm pitch, providing secure and precise alignment on printed circuit boards. Its polybutylene terephthalate housing ensures electrical insulation and mechanical durability while maintaining heat resistance across an operating temperature range from -55°C to 125°C.
The contacts are crafted from copper alloy plated with gold to ensure excellent conductivity and corrosion resistance under demanding environments. The shrouded design offers additional protection, preventing accidental contact damage and enhancing overall connector safety.
This product uses through-hole mounting technique which provides strong mechanical connection suitable for high-reliability applications in electronic assemblies, manufacturing, and prototyping. Rated for 1 amp current and 1 kilovolt voltage, this header supports a range of low voltage power and signal applications.
The connector complies with industry expectations for quality and durability, being manufactured in Switzerland. It suits applications in electronics manufacturing, repair, and integration within devices requiring secure PCB connections.
The connector system is wire-to-board, suitable for diverse custom wiring needs. Termination type is solder, ensuring firm and lasting joint on PCB. Locking levers are available for additional stability as separate items.
It is part of the SEK 18 series known for modular and versatile interconnect solutions. Common uses include circuit board assembly, industrial controls, and electronic instrumentation. Explore more from HARTING and other quality connectors in the PCB Headers category on EnvMart for your electronic components requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The connector has a current rating of 1A, making it suitable for low power applications.
It has a voltage rating of 1 kV, providing robust electrical insulation.
The operating temperature range is from -55°C to 125°C, ensuring performance under varied conditions.
This model uses through-hole mounting, which provides a strong mechanical connection suitable for high-reliability applications.
It features a polybutylene terephthalate housing for insulation, and the contacts are made of copper alloy plated in gold for conductivity and corrosion resistance.
It has a total of six male contacts arranged in two rows with a pitch of 2.54 mm.
The termination type is solder, ensuring a firm and lasting joint on the PCB.
This connector is shrouded, providing enhanced protection against accidental contact and mechanical damage.
The connector is manufactured in Switzerland, ensuring adherence to industry quality standards.
It is suitable for wire-to-board connection systems in industrial, commercial, and laboratory electronics applications.
The contact gender is male, designed to fit appropriate PCB sockets.
Locking levers are available as separate items for additional stability in the connection.
