KEMET 22 nF Multilayer Ceramic Capacitor, 100V dc, ±10% Tolerance, Through Hole Radial Mount, X7R Dielectric C322C223K1R5TA
Specifications
| Country of Origin | Mexico |
|---|---|
| Voltage | 100V dc |
| Brand | KEMET |
| Height | 6.6mm |
| Length | 5.08mm |
| Model | C322C223K1R5TA |
| Packaging | Tape & Reel |
| Width | 3.81mm |
| Mount Type | Through Hole |
| Series | Goldmax 300 |
| Termination Type | Radial |
| Maximum Operating Temperature | 125°C |
| Tolerance | ±10 % |
| Capacitance | 22nF |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | REACH, RoHS, UL |
| Lead Diameter | 0.51mm |
| Dielectric | X7R |
| Suppression Class | Class I |
| Lead Spacing | 5.08mm |
Key Features
- Capacitance of 22 nF suitable for various electronic applications.
- X7R dielectric ensures stability over temperature range.
- Rated for 100V dc voltage operation.
- Radial lead type through hole mounting for circuit integration.
- Operating temperature range from -55°C to 125°C.
- Compact dimensions of 6.6 mm height, 5.08 mm length, and 3.81 mm width.
- Package supplied in tape & reel format for automated assembly.
- Lead spacing of 5.08 mm and lead diameter of 0.51 mm for compatibility.
Product Description
KEMET C322C223K1R5TA is a 22 nF Multilayer Ceramic Capacitor, designed for high reliability in electronic circuits. This component features a through hole radial mounting style, facilitating easy insertion and soldering on printed circuit boards. It utilizes an X7R dielectric, ensuring stable capacitance across a wide temperature range from -55°C to 125°C, making it suitable for demanding industrial and commercial applications.
The capacitor is rated for a maximum working voltage of 100V dc and offers a tolerance of ±10%, allowing precise control in filtering, timing, and decoupling applications. Its compact physical dimensions - 6.6 mm in height, 5.08 mm length, and 3.81 mm width - help minimize space usage in electronic assemblies. The radial leads have a spacing of 5.08 mm and a diameter of 0.51 mm, optimized for standard PCB hole layouts.
This model is part of the Goldmax 300 series, known for low equivalent series resistance (ESR) and suitability as snubbers or filters in telecommunications, medical equipment, military, and aerospace sectors. KEMET capacitors conform to international standards including REACH, RoHS, and UL, ensuring quality and environmental compliance. The product originates from Mexico and is packaged in convenient tape & reel format for automated manufacturing processes.
Capacitance of 22 nF suitable for varied electronics applications. X7R dielectric offers temperature stability and reliability. Rated for 100V dc voltage ensuring safe operation. Radial through hole leads enable secure PCB mounting.
Wide operating temperature range from -55°C to 125°C. Compactly sized at 6.6 mm height and 5.08 mm length. Compliant with REACH, RoHS, and UL standards. Goldmax 300 series optimized for low ESR and high-frequency performance.
This high-quality Multilayer Ceramic Capacitor is ideal for industrial, telecommunications, medical, military, and aerospace electronic circuits requiring stable capacitance and durability. Explore the comprehensive electronics components category on EnvMart for similar high-performance capacitors and passive components suitable for your project needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance of 22 nF, making it suitable for various electronic applications.
It is rated for a maximum operating voltage of 100V dc.
This capacitor utilizes an X7R dielectric, which ensures stable capacitance over a wide temperature range.
The operating temperature range is from -55°C to 125°C.
It has compact dimensions of 6.6 mm in height, 5.08 mm in length, and 3.81 mm in width.
The lead spacing is 5.08 mm, and the lead diameter is 0.51 mm, which is optimized for standard PCB hole layouts.
It is supplied in tape & reel format, which is suitable for automated assembly processes.
This model is part of the Goldmax 300 series, known for its low equivalent series resistance (ESR).
It conforms to international standards including REACH, RoHS, and UL, ensuring quality and environmental compliance.
The capacitor has a tolerance of ±10%, allowing for precise control in various applications.
This model features a through hole radial mounting style, facilitating easy insertion and soldering on printed circuit boards.
It is suitable for demanding industrial and commercial applications, including telecommunications, medical equipment, military, and aerospace sectors.
