Honeywell Technologies Piezoresistive Pressure Sensor Through Hole 8 Pin DIP Package SSCDRRN001PDAA5
Specifications
| Country of Origin | India |
|---|---|
| Accuracy | ±0.25 % |
| Brand | Honeywell |
| Maximum Operating Pressure | 0.1 kPa |
| Height | 13.75mm |
| Length | 10mm |
| Model | SSCDRRN001PDAA5 |
| Sensor Type | Piezoresistive Pressure Sensor |
| Mount Type | Through Hole |
| Series | SSC |
| Maximum Operating Temperature | 85°C |
| Port Type | Dual Radial Barbed |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Pin Count | 8 |
| Maximum Supply Voltage | 5V |
| Minimum Supply Voltage | 3.3V |
| Minimum Operating Pressure | 1psi |
| Maximum Overload Pressure | 1kPa |
Key Features
- Operates with a supply voltage range of 3.3V to 5V.
- Offers high accuracy with ±0.25% measurement precision.
- Designed for through-hole mounting with an 8-pin DIP package.
- Supports a pressure range up to 0.1 kPa maximum operating pressure.
- Compact dimensions with a length of 10 mm and a height of 13.75 mm.
- Capable of operating temperatures from -40°C to 85°C.
- Features dual radial barbed ports for secure pressure connections.
- Includes ASIC-based temperature compensation and offset calibration.
Product Description
Honeywell SSCDRRN001PDAA5 is a high precision piezoresistive pressure sensor designed for reliable pressure measurement in electronic and industrial applications. Featuring an 8-pin DIP package for through-hole mounting, this sensor is calibrated and temperature compensated using an onboard ASIC to ensure accuracy and stability throughout the operating range.
It operates with supply voltages of 3.3V to 5V, offering flexibility for integration with various electronic systems. The sensor has a maximum operating pressure of 0.1 kPa and a maximum overload pressure up to 1 kPa, suitable for low-pressure sensing tasks.
Compact and robust, with dimensions 10 mm in length and 13.75 mm in height, and a dual radial barbed port type, the sensor ensures secure connectivity and durability. Its operating temperature range from -40°C to 85°C makes it suitable for industrial, automotive, HVAC, and laboratory instrumentation environments.
The device is fully calibrated for sensor offset, sensitivity, and non-linearity, which reduces the need for additional customer calibration and improves system efficiency and reliability. This sensor helps minimize downtime by detecting most internal failures, including burst sensors, thus enhancing overall system longevity.
Operates at supply voltages of 3.3V to 5V for versatile integration. Provides highly accurate readings with ±0.25% accuracy. Manufactured in the SSC series with ASIC temperature compensation. Supports through-hole mounting with an 8-pin DIP package.
Dimensioned 10 mm length by 13.75 mm height for compact installations. Dual radial barbed ports for reliable pressure input connections. Wide operating temperature range from -40°C to 85°C.
This Honeywell Technologies piezoresistive Pressure Sensor is ideally suited for use in industrial tools, electronic equipment, HVAC systems, laboratory measurement setups, and automotive sensor applications. Its robust design and precise calibration make it a dependable component for pressure sensing needs.
Explore more sensor ICs and pressure measurement instruments in the Electronics & Electricals category at EnvMart for comprehensive solutions tailored to your industrial requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating pressure of this sensor is 0.1 kPa.
This model offers high accuracy with ±0.25% measurement precision.
It operates with a supply voltage range of 3.3V to 5V.
The sensor has compact dimensions of 10 mm in length and 13.75 mm in height.
This model is designed for through-hole mounting with an 8-pin DIP package.
It can operate in temperatures ranging from -40°C to 85°C.
It includes dual radial barbed ports for secure pressure connections.
The maximum overload pressure is up to 1 kPa.
The sensor is fully calibrated for offset, sensitivity, and non-linearity, reducing the need for additional customer calibration.
This sensor is suitable for industrial tools, electronic equipment, HVAC systems, laboratory measurement setups, and automotive sensor applications.
The minimum operating pressure is 1 psi.
This model is manufactured in the SSC series.
