Cree LED 5 mm Red Through Hole LED 2.6 V 130 mW 50 mA C503B-RAN-CA0B0AA1
Specifications
| Country of Origin | China |
|---|---|
| Brand | Cree LED |
| Model | C503B-RAN-CA0B0AA1 |
| Packaging | Bulk |
| Mount Type | Through Hole |
| Series | Cree |
| Maximum forward current | 50mA |
| Viewing angle | 15 ° |
| Package Type | 5 mm (T-1 3/4) |
| Standards/Approvals | RoHS |
| LED Colour | Red |
| Dominant Wavelength | 630nm |
| Forward Voltage | 2.6V |
| Number of Pins | 2 |
| LED Luminosity | 23500 mcd |
| Maximum Power Dissipation | 130mW |
| Lens Dimensions | 8.8 x 5 mm |
| Lens Shape | Round |
| Cree2.6 V Red LED 5mm Through Hole, C503B-RAN C503B-RAN-CZ0A0AA1Brand | Cree |
Key Features
- The LED emits a dominant wavelength of 630 nm, producing vibrant red light.
- Maximum power dissipation of 130 mW ensures stable and efficient light output.
- The round lens with dimensions of 8.8 x 5 mm has a clear finish and a narrow 15 degree viewing angle for focused illumination.
- The device features two pins for through-hole mounting on PCB assemblies.
- Constructed using optical-grade epoxy resin, providing temperature and moisture resistance suitable for outdoor electronic signage.
- Conforms to RoHS standards, ensuring compliance with environmental regulations.
- Designed for applications such as electronic signs, variable message signs, advertising signs, and petrol station indicators.
Product Description
The Cree LED model C503B-RAN-CA0B0AA1 is a 5 mm (T-1 3/4) through-hole light emitting diode with a red emission color, forward voltage of 2.6 V, and maximum forward current of 50 mA. It provides a high LED luminosity of 23,500 mcd and a dominant wavelength of 630 nm, making it suitable for applications where bright and clear red indication is required.
This LED uses a round, clear lens measuring 8.8 x 5 mm that offers a narrow 15° viewing angle for focused light output. The LED is manufactured using optical-grade epoxy resin, granting it resistance to temperature changes and moisture. It is compliant with RoHS environmental standards.
Its robust performance and stable light output over extended periods make it ideal for industrial and commercial use in electronic signs, variable message signs, petrol signs, amusement applications, and outdoor signal boards.
High-intensity red light emission for excellent visibility. Through-hole mounting with two pins for easy PCB installation. Temperature and moisture resistant epoxy resin construction. Compact 5 mm package size with clear lens design.
Complies with RoHS environmental directives. Durable performance suitable for indoor and outdoor applications. Designed for electronic signage, variable message systems, and advertising displays.
This Cree LED C503B-RAN-CA0B0AA1 is manufactured in China and is provided in bulk packaging for efficient volume use. It is a reliable component for industrial, commercial, and electronic manufacturing purposes.
Explore more Cree LED products and related electronic components in the Lighting and LED categories at EnvMart to find the optimal components for your application requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The forward voltage of this LED is 2.6 V.
The maximum forward current for the C503B-RAN-CA0B0AA1 is 50 mA.
This LED has a luminosity of 23,500 mcd, providing high brightness.
The dominant wavelength of this LED is 630 nm, producing vibrant red light.
It has a narrow viewing angle of 15 degrees, allowing for focused illumination.
The lens dimensions are 8.8 x 5 mm, featuring a round shape with a clear finish.
This model features through-hole mounting with two pins for easy installation on PCB assemblies.
It is constructed using optical-grade epoxy resin, providing resistance to temperature and moisture.
Yes, it conforms to RoHS standards, ensuring compliance with environmental regulations.
This LED is designed for applications such as electronic signs, variable message signs, and petrol station indicators.
This LED is manufactured in China.
The LED is provided in bulk packaging for efficient volume use.
