KEMET R75 Polypropylene Film Capacitor, 680 nF Capacitance, 5% Tolerance, 160 V DC, 90 V AC, Through Hole R75GI368050H0J

Free Delivery in India | Lowest Global Shipping Charges

KEMET R75 Polypropylene Film Capacitor, 680 nF Capacitance, 5% Tolerance, 160 V DC, 90 V AC, Through Hole R75GI368050H0J

Name: KEMET R75 Polypropylene Film Capacitor, 680 nF Capacitance, 5% Tolerance, 160 V DC, 90 V AC, Through Hole R75GI368050H0J
Brand: KEMET
SKU: 109645
Price: 20.22 USD
Availability: InStock



Category Film Capacitors Brand KEMET Condition New

Specifications

Country of Origin	China
Brand	KEMET
Height	14.5mm
Length	18mm
Model	R75GI368050H0J
Packaging	Tape & Reel
Width	8.5mm
Mount Type	Through Hole
Series	R75
Maximum Operating Temperature	105°C
Tolerance	5 %
Capacitance	680nF
Minimum Operating Temperature	-55°C
Dissipation Factor	0.05%
Lead Length	25mm
Standards/Approvals	RoHS, IEC 60286-2
Package/Case	Plastic
Pin Count	2
Rated AC Voltage	90V ac
Rated DC Voltage	160V dc
Lead Pitch	15mm
Lead Diameter	0.8mm
Automotive Standard	AEC-Q200
Equivalent Series Resistance ESR	7mΩ

Key Features

Polypropylene film dielectric ensures excellent stability and low losses.
5% capacitance tolerance for precise circuit performance.
Rated for up to 160 V DC and 90 V AC voltage applications.
Through hole mount with radial leads and 15 mm lead pitch for easy PCB insertion.
Designed for high-frequency, medium to high current, resonant circuit, and silicon controlled rectifier applications.
Encapsulated in a plastic, self-extinguishing, solvent resistant case for durability.
Operates reliably between -55°C to 105°C maximum temperature.
Lead free terminations and RoHS compliant for environmental safety.

Product Description

KEMET R75GI368050H0J is a polypropylene film capacitor featuring a capacitance of 680 nF with a tight tolerance of 5%. It is designed for through hole mounting with radial leads and a lead pitch of 15 mm, suitable for printed circuit board applications. This capacitor handles rated DC voltage of 160 V and AC voltage of 90 V, making it ideal for high-frequency and medium to high current circuits.

The capacitor casing is made from a self-extinguishing, solvent resistant plastic with thermosetting resin, ensuring durability and safety in demanding environments. It complies with stringent standards including RoHS and IEC 60286-2, and meets the automotive AEC-Q200 standard, assuring high reliability.

Operating temperature ranges from -55°C to a maximum of 105°C, supporting a variety of industrial and automotive applications such as resonant circuits, silicon controlled rectifiers, and other power electronics requiring stable capacitance and low equivalent series resistance of 7 mΩ.

The leads have a length of 25 mm and diameter of 0.8 mm, facilitating secure and reliable soldering. The capacitor is supplied in tape and reel packaging, optimized for automated pick and place assembly.

Polypropylene dielectric providing low dissipation factor of 0.05% and high electrical stability. Encapsulated design protects against solvent and physical damage. Lead-free terminations ensure compliance with environmental regulations.

High reliability suitable for automotive and industrial electronics. Designed for medium-power resonant and switching power applications.

This KEMET film capacitor is widely used in industrial electronics, automotive circuits, power supplies, and HVAC control systems. Its robust design and stringent certifications make it a dependable choice for engineers and manufacturers.
