Amphenol Industrial MIL Spec Circular Connector Panel Mount 1kV AC 8 Way Female Copper Alloy PT02E-16-8S
Specifications
| Country of Origin | accordance with MIL-DTL- |
|---|---|
| Voltage | 1kV ac |
| Brand | Amphenol Industrial |
| Colour | Green |
| Orientation | Straight |
| Model | PT02E-16-8S |
| Mount Type | Panel Mount |
| Housing Material | Aluminium |
| Contact Material | Copper Alloy |
| Series | PT |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Female |
| Connector Gender | Female |
| Shell Size | 16 |
| Military Standard | MIL-DTL-26482 |
| Mating Type | Bayonet |
| Connector Size | Miniature |
| Shell Plating | Cadmium |
Key Features
- This MIL-DTL-26482 compliant connector supports 8 female contacts.
- It features a green aluminium housing with cadmium plating for durability.
- Connector is designed for 1kV AC voltage rating.
- Operating temperature ranges from -55°C to 125°C ensuring wide environmental tolerance.
- The solder termination type guarantees secure and stable connections.
- Compact miniature shell size 16 with straight orientation provides ease of integration.
- Gold plated copper alloy contacts assure excellent conductivity and corrosion resistance.
- The bayonet mating type enables rapid and secure connection and disconnection.
Product Description
Amphenol Industrial PT02E-16-8S is a high-quality MIL Spec Circular Connector designed for demanding industrial and military applications. This 8 way female panel mount connector features a miniature shell size 16, constructed with an aluminium housing plated with cadmium to provide excellent mechanical durability and corrosion resistance. The contacts are made from copper alloy with gold plating to enhance electrical conductivity and reliability under harsh conditions.
Operating at a voltage of 1kV AC, this connector supports environments with temperatures ranging from -55°C to 125°C, making it suitable for a wide range of industrial and defense equipment operating scenarios. The straight orientation combined with bayonet coupling mechanism ensures secure and fast mating, minimizing downtime during assembly or maintenance.
The solder termination type allows for robust cable connections, ideal for systems requiring reliable, long-term electrical contact. Manufactured following MIL-DTL-26482 standards, the PT series connectors are intermountable with other MIL-DTL-26482 connectors, providing versatility and ease of replacement or upgrades.
This connector is widely used in industrial automation, military electronics, aerospace, telecommunications, and harsh environment instrumentation. It is suitable for applications where reliable power and signal transmission are critical under demanding conditions.
This MIL-DTL-26482 compliant connector supports 8 female contacts. It features a green aluminium housing with cadmium plating for durability. Connector is designed for 1kV AC voltage rating. Operating temperature ranges from -55°C to 125°C ensuring wide environmental tolerance.
The solder termination type guarantees secure and stable connections. Compact miniature shell size 16 with straight orientation provides ease of integration. Gold plated copper alloy contacts assure excellent conductivity and corrosion resistance.
The bayonet mating type enables rapid and secure connection and disconnection.
Explore our Electronics Components category for a wide range of high-quality circular connectors and related accessories for industrial, military, and commercial applications on EnvMart.
Explore more products in our Mil Spec Circular Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This connector is designed for a voltage rating of 1kV AC.
The operating temperature range is from -55°C to 125°C.
It features 8 female contacts.
The housing is made of aluminium with cadmium plating, and the contacts are copper alloy with gold plating.
It utilizes a solder termination type for secure connections.
This model has a miniature shell size of 16.
It features a bayonet mating type for rapid and secure connections.
Yes, it is manufactured in accordance with MIL-DTL-26482 standards.
The housing is green in color.
It is suitable for industrial automation, military electronics, aerospace, telecommunications, and harsh environment instrumentation.
The connector has a straight orientation, facilitating ease of integration.
The maximum operating temperature is 125°C.
