Honeywell Technologies Differential Pressure Sensor 3.3V-5V 6-Pin SMT Surface Mount HSCMRRD005ND2A3
Specifications
| Country of Origin | China |
|---|---|
| Accuracy | ±0.25 % |
| Brand | Honeywell |
| Maximum Operating Pressure | 34.5 kPa |
| Height | 13.75mm |
| Length | 10mm |
| Model | HSCMRRD005ND2A3 |
| Sensor Type | Differential Pressure Sensor |
| Mount Type | Surface |
| Series | HSC |
| Maximum Operating Temperature | 85°C |
| Port Type | Dual Radial Barbed |
| Package Type | SMT |
| Minimum Operating Temperature | -20°C |
| Pin Count | 6 |
| Maximum Supply Voltage | 5V |
| Minimum Supply Voltage | 3.3V |
| Minimum Operating Pressure | -5in/H2O |
| Maximum Overload Pressure | 2068kPa |
Key Features
- Provides ±0.25% accuracy for reduced calibration effort.
- Operates from a single 3.3V to 5V supply for flexible design.
- Fast response time down to 0.46ms for rapid pressure updates.
- Dual radial barbed ports enable easy tubing connections.
- Wide operating temperature range from -20°C to 85°C.
- Suitable for measuring differential pressure of non-corrosive gases and select liquids.
- Compact size with 13.75mm height and 10mm length for board mount applications.
- Low power consumption, typically less than 10mW, extends battery life.
Product Description
Honeywell Technologies HSCMRRD005ND2A3 is a differential pressure sensor designed for precision measurement of pressure differences in non-corrosive, non-ionic gases and selected liquids. The device features a surface mount SMT package with 6 pins, suitable for compact PCB integration.
This sensor operates from a single power supply between 3.3V and 5V and incorporates an on-board ASIC providing calibrated ratiometric analogue or digital outputs with swift update rates approximately 1 kHz analogue or 2 kHz digital. The sensor offers a high accuracy of ±0.25%, reducing software calibration effort and ensuring reliable measurements.
Equipped with dual radial barbed ports, it simplifies tubing connectivity for various applications. The compact dimensions of 13.75mm height and 10mm length enable efficient board mounting without sacrificing performance. It withstands a wide temperature range from -20°C to 85°C, making it suitable for high temperature environments.
Typical low power consumption under 10mW supports battery-powered applications. The sensor provides robust performance with vibration and shock resistance, suitable for millions of pressure cycles.
±0.25% accuracy reduces calibration complexity. Single 3.3V to 5V supply for design flexibility. Fast response times improve measurement updates. Dual radial barbed ports for easy tubing connection. Compact 6-pin SMT surface mount packaging.
Wide operational temperature range from -20°C to 85°C. Low power consumption extends operational life. Highly durable with vibration and shock resistance. Applications include HVAC, respiratory machines, gas flow, and environmental monitoring.
This sensor is commonly employed in HVAC systems for clogged filter detection, ventilator differential sensing, oxygen concentrators, gas flow instrumentation, and environmental barometry. Its robust design and precision make it suitable for laboratory, industrial, medical, and environmental applications.
Browse EnvMart for additional Honeywell Pressure Sensors and differential pressure measurement solutions suited to your industrial and electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The sensor provides an accuracy of ±0.25%, which helps reduce calibration effort.
It operates from a single supply voltage between 3.3V and 5V, allowing for design flexibility.
The sensor features a fast response time of approximately 0.46 milliseconds for rapid pressure updates.
This model has a height of 13.75mm and a length of 10mm, making it suitable for compact board mount applications.
It is suitable for measuring differential pressure of non-corrosive gases and select liquids.
The maximum operating temperature is 85°C, allowing it to function in high-temperature environments.
The sensor features a 6-pin configuration and comes in a surface mount (SMT) package type.
The maximum operating pressure is 34.5 kPa, with a maximum overload pressure of 2068 kPa.
It is equipped with dual radial barbed ports, which facilitate easy tubing connections.
Typical power consumption is less than 10mW, which helps extend battery life in applications.
It is commonly used in HVAC systems, respiratory machines, gas flow instrumentation, and environmental monitoring.
It can operate within a wide temperature range from -20°C to 85°C and is designed to be resistant to vibration and shock.
