Yageo 220 nF 50V dc ±10 % Multilayer Ceramic Capacitor, Surface Mount, X7R Dielectric CS0603KRX7R9BB224
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 50V dc |
| Brand | Yageo |
| Height | 0.8mm |
| Length | 1.6mm |
| Model | CS0603KRX7R9BB224 |
| Packaging | Paper/PE Tape Reel |
| Width | 0.8mm |
| Mount Type | Surface |
| Construction | Stacked |
| Series | Standard |
| Termination Type | Surface Mount |
| Maximum Operating Temperature | 125°C |
| Tolerance | ±10 % |
| Capacitance | 220nF |
| Minimum Operating Temperature | -55°C |
| Package/Case | 0603 |
| Dielectric | X7R |
| Suppression Class | X7R |
Key Features
- High capacitance of 220 nF ensures stable electrical performance.
- Dielectric type is X7R, providing temperature stability up to 125°C.
- Standard 0603 package size with dimensions 1.6mm x 0.8mm x 0.8mm.
- Features ±10% tolerance for precise circuit behavior.
- Lead-free termination complying with RoHS standards.
- Suitable for high flexure stress circuit boards and switch power supplies.
- Packaging in tape on reel supports automated assembly.
- Meets IEC 60384-1, IEC 60384-21/22 standards assuring quality and reliability.
Product Description
Yageo CS0603KRX7R9BB224 is a 220 nF multilayer ceramic capacitor designed for surface mount applications, delivering 50V dc voltage capability and ±10% tolerance. This X7R series capacitor features a compact 0603 package size measuring 1.6mm length, 0.8mm width, and 0.8mm height, making it ideal for dense circuit board layouts.
Constructed with stacked layers and lead-free terminations, it is compliant with RoHS directives and meets IEC 60384 standards including parts 1 and 21/22. Its X7R dielectric material ensures stable capacitance across a wide temperature range from -55°C to 125°C, providing robustness in demanding industrial and telecom applications.
This component is designed to withstand high mechanical flexure stress, commonly encountered in switch mode power supplies and telecommunication base stations. The tape on reel packaging facilitates high-volume automated pick-and-place assembly processes, improving manufacturing efficiency.
High capacitance of 220 nF ensures stable electrical performance. Voltage rating of 50V dc suitable for various electronic applications. Dielectric type is X7R, providing temperature stability up to 125°C. Standard 0603 package size with dimensions 1.6mm x 0.8mm x 0.8mm.
Features ±10% tolerance for precise circuit behavior. Lead-free termination complying with RoHS standards. Suitable for high flexure stress circuit boards and switch power supplies. Packaging in tape on reel supports automated assembly.
Meets IEC 60384-1, IEC 60384-21/22 standards assuring quality and reliability.
This Yageo Multilayer Ceramic Capacitor is an excellent choice for industrial electronics, telecommunications, automotive electronics (non-automotive standard), and commercial manufacturing sectors. Its rated operating temperature and mechanical strength ensure long service life and reliability under operational stresses.
Explore our comprehensive Electronics Components range at EnvMart for high-quality passive components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a capacitance value of 220 nF.
It is rated for a voltage of 50V dc.
The capacitor has dimensions of 1.6mm in length, 0.8mm in width, and 0.8mm in height.
It uses X7R dielectric material, which provides temperature stability up to 125°C.
The tolerance for this model is ±10%.
The operating temperature range is from -55°C to 125°C.
It features lead-free termination, complying with RoHS standards.
This capacitor is suitable for high flexure stress circuit boards and switch mode power supplies.
It is packaged in tape on reel, which supports automated assembly processes.
It meets IEC 60384-1, IEC 60384-21/22 standards, ensuring quality and reliability.
The capacitor is constructed with stacked layers.
This model is designed for surface mount applications.
