Yageo 220 nF Multilayer Ceramic Capacitor 50V DC ±10% Tolerance Surface Mount 0805 Package CC0805KKX7R9BB224

The Yageo CC0805KKX7R9BB224 is a 220 nF multilayer ceramic capacitor designed for surface mount technology applications. It features a compact 0805 package size with dimensions of 2mm length, 1.25mm width, and 0.6mm height, enabling its use in modern compact electronic assemblies.

This capacitor utilizes a stacked construction and X7R dielectric material, which provides stable capacitance across a wide temperature range from -55°C to 125°C. Its rated voltage is 50V DC with a tolerance of ±10%, making it suitable for various electronic circuits requiring precise and reliable capacitance.

The device termination is coated with lead-free plated tin, ensuring compliance with environmental standards such as RoHS. It is packaged in tape and reel format, facilitating efficient automated placement in manufacturing processes.

The capacitor meets international standards IEC 60384-1 and IEC 60384-21/22, underscoring its quality and reliability. Classified as a Class II suppression capacitor, it is engineered for standard series applications in electronics.

The capacitor features stacked construction for compact and reliable performance. It uses X7R dielectric material supporting a temperature range of -55°C to 125°C. Surface mount termination with lead-free plated tin ensures environmental compliance.

Dimensions are 2mm length, 1.25mm width, and 0.6mm height suitable for compact circuit boards. Packaging supplied in tape and reel format for automatic pick-and-place assembly. Conforms to standards IEC 60384-1 and IEC 60384-21/22, RoHS compliant.

Class II suppression class capacitor designed for standard series applications.

This product is ideal for industrial, consumer electronics, automotive electronics, and manufacturing applications requiring dependable Multilayer Ceramic Capacitors. It supports efficient circuit design, mass production, and high performance in demanding environments.
