Wurth Elektronik WE-CNSW Surface RFI Filter 320mA 50V dc 10MHz-1000MHz Surface Mount 1 Phase 744233670
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Height | 2mm |
| Length | 1.2mm |
| Depth | 1.2mm |
| Packaging | Tray & Carton |
| Mount Type | Surface |
| Operating Frequency | 10, 1000MHz |
| Series | WE-CNSW |
| Maximum Operating Temperature | 125°C |
| Capacitance | 0.47μF |
| Minimum Operating Temperature | -40°C |
| Maximum Current | 320mA |
| Number of Phases | 1 |
| Leakage Current | 369μA |
| Maximum Voltage | 50V dc |
| Inductance | 11μH |
| Standards/Approvals | VDE, UL |
| Termination Style | Surface Mount |
Key Features
- Operates effectively across 10MHz to 1000MHz frequency range.
- Compact dimensions with 1.2mm length, 1.2mm depth, and 2mm height.
- Features capacitance of 0.47μF and inductance of 11μH for common mode noise filtering.
- Low leakage current of 369μA ensures minimal power loss.
- Supports operating temperature range from -40°C to 125°C for durability.
- Surface mount termination style suitable for efficient PCB mounting.
- Complies with VDE and UL standards ensuring safety and reliability.
- Supplied in tray and carton packaging for safe transport and handling.
Product Description
Wurth Elektronik 744233670 Surface RFI Filter is a single phase, surface mount common mode choke designed to suppress EMI noise at high frequencies ranging from 10MHz up to 1000MHz. It supports a maximum current rating of 320mA and maximum voltage of 50V dc, making it suitable for use in sensitive electronic equipment demanding high noise immunity.
This filter exhibits a capacitance of 0.47μF and an inductance of 11μH, optimized to provide high common mode suppression while maintaining minimal impact on signal integrity due to winding symmetry. It features a low leakage current of 369μA, ensuring efficient power usage in applications.
The compact size with dimensions 1.2mm (length) × 1.2mm (depth) × 2mm (height) allows for easy integration onto compact PCBs. The surface mount termination style facilitates efficient automated PCB assembly and improves production throughput. Operating temperature range from -40°C to 125°C guarantees performance stability across harsh environmental conditions.
Certified to VDE and UL safety standards, this filter assures quality and reliability for industrial, consumer electronics, telecommunications, and data communication line applications. It is commonly used in USB 2.0, Firewire, LAN, LVDS, and other high speed data lines where common mode noise must be minimized.
Operates within a broad frequency range from 10MHz to 1000MHz for effective EMI noise suppression.
Compact dimensions and surface mount package suit high density PCB layouts. Low leakage current and winding symmetry reduce power losses and signal distortion. Wide operating temperature guarantees reliable functionality under demanding conditions.
Compliant with international safety standards including VDE and UL. Ideal for industrial electronics, telecommunications, and data communications systems. Packaged to optimize manufacturing efficiency and product protection.
Explore more electronics components like EMI Filters and surface mount inductors at EnvMart for your industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates effectively across a frequency range from 10MHz to 1000MHz.
The filter has compact dimensions of 1.2mm in length, 1.2mm in depth, and 2mm in height.
The maximum current rating for this filter is 320mA.
It features a capacitance of 0.47μF and an inductance of 11μH.
The operating temperature range is from -40°C to 125°C.
It has a surface mount termination style, suitable for efficient PCB mounting.
It complies with VDE and UL standards, ensuring safety and reliability.
The filter has a low leakage current of 369μA, ensuring minimal power loss.
It is commonly used in USB 2.0, Firewire, LAN, LVDS, and other high-speed data lines to minimize common mode noise.
The maximum voltage rating is 50V dc.
It is supplied in tray and carton packaging for safe transport and handling.
It is suitable for industrial, consumer electronics, telecommunications, and data communication line applications.
