Atomic Absorption Spectrometer AA301

Name: Atomic Absorption Spectrometer AA301
Brand: EnvMart
SKU: AAFSH
Availability: InStock

₹1

Enquire Now

Tax included

Quantity

Specifications

Weight	35 kg
Dimensions	815 mm (L) x 285 mm (W) x 495 mm (H)
Mounting	Littrow type
Wavelength Range	190 to 900 nm
Bandwidth	Variable 0.1 to 2 nm in steps of 0.1 nm
SENSITIVITY	Greater then 0.7 Abs signal for 5 ppm Copper solution 3.
Power Required	230 Volts 10 %\| 50 Hz\| 69 VA
Detector	High performance photomultiplier.
Photometric Range	-0.301 to 2.0 Abs
Photometric Accuracy	0.001 Abs @ 1 Abs
Grating	1200 lines/mm
Focal Length	250 nm
Spray Chamber	Chemically inert\| PTFE.
Gas Control	Gas flow rate control with rota meter and needle valves. Software controlled flame type change over from air/acetylene to nitrous oxide/acetylene.
NEBULIZER	Platinum\| Iridium.
Lamp Capacity	2lamp positions with individual power supply.
Sample Uptake Rate	5 to 8 ml/min
Burner Type	Air cooled\| pre-mix 100 mm slot burner suitable for acetylene/air flames. Universal 50 mm slot burner suitable for all flame types 2.
Burner Positioning	Manual vertical\| rotational and lateral positioning.
Flame Ignition and Extinguish	Manual
Operational Modes	Atomic absorption\| atomic absorption with background correction 1\| emission.

Key Features

Atomic absorption with background correction requires additional D2 background correction option
50 mm burner optional. Compatible with air/acetylene and nitrous oxide/acetylene flame types

Reference AAFSH Category Spectrophotometer

Product Details

AA301 Atomic Absorption Spectrometer has been developed to guide the user quickly and easily through an analysis with its comprehensive Elemental Method Library. The AA301 comes with intuitive AA software for simple data acquisition and system control.Analysis is fast and simple with these performance enhancingfeatures:Better performance is achieved with an improved spray chamber and nebulizermaking the sample introduction process more efficient and repeatableValuable time is saved with the twin lamp holder, allowing one lamp to beused for measurement whilst the other is warming up Various options and accessories are available to enhance performance and functionality including background correction, hydride generator, cold vapour mercury generator and 50 mm nitrous oxide/acetylene burne Convenient lamp selection via ElementName or Lamp Holder Number Wavelength peaks can be searched and found automatically by selecting different parameters Always see what is happening with the real time continuous display of absorbance scan vs time Safe pneumatics controller including safety interlock before flame ignition,extinguish or flame type changeover Continuous monitoring of flame andinstrument status indicated clearly by color Analytical parameters for all AA elements are stored in an easily accessible cookbook.
