\Single Deck Flat Sheet Membrane 125 Cassettes FSMBR 05-125

₹1
Enquire Now
Quantity
Add to Cart

Specifications

Model FSMBR 05-125
Length 1695 mm
pH Range 06-09 pH
Width 600 mm
Plate material ABS
Operating Temperature 5 -40 degree c
Membrane Material PVDF
Dry Weight 1 Kg
Membrane effective area (m 2 ) 62.5
Standard Height 1300 mm
Air Flowrate (l/min) 625
Membrane pore size(Micro meter) 0.1
Output turbidity(NTU) Less Than 1.0
Output SS(mg/L) Less Than -5
Chemical cleaning 5000mg/l NaClO
Design Flux LMH 15-34 LMH
MLSS 7000-l8000 PPM
DO Concentration Greater Than 1 PPM
Operating Trans. Pressure 50-200 Mbar
Operating mode(permeate/relaxation) 08-02 Min
Max press drop 350 Mbar
MOC of Frame SS-304/SS316
No. of Cassettes 125

Key Features

  • Permanently hydrophilic
  • High MLSS concentration
  • High Flux & low fouling
Reference ABZIJ Category Ultrafiltration Membranes

Product Details

FSMBR 05 Single Deck Flat Sheet Membrane 125 Cassettes (Model No. FSMBR 05-125), FMBR PVDF Series is a high-flux Flat Sheet MBR membrane delivering excellent permeability, fouling resistance, stability, and elimination effectiveness. Structured with PVDF (permanently hydrophilic polyvinyl difluoride) has the advantage of dry storage. FMBR PVDF Series membranes can be used for a wide variety of treatment applications such as industrial and domestic wastewater.
  • High chlorine resistance
