0-5000 Um Coating Thickness Gauge EC-900

Name: 0-5000 Um Coating Thickness Gauge EC-900
Brand: EnvMart
SKU: ACDIU
Price: 17843 INR
Availability: InStock

₹26,601

₹17,843 Save ₹8,758

Tax included

Quantity

Specifications

Accuracy	(1%+5 um)
Resolution	0~99.9um(0.1um) others(1um)
Power Supply	Three 1.5 V AAA battery
Calibration	One point to four points calibration zero point calibration
Measuring range	Up to 10000 um
Computer Interface	Download data via USB
Alarm	User can set the high/low alarm limit\| Alarm icon displayed on LCD when over the limit
Measuring Principle	Magnetic induction & Eddy Currents
Probe	F-Probe & N-Probe
Model Name / Number	EC-900
Data Group	Four general groups (readings will be stored automatically) One direct group(readings not be stored to memory)
Statistics	No. of readings mean minimum maximum and standard deviation
Minimum Curvature Radius Convex	1.5 mm
Minimum Curvature Radius Concave	25 mm
Minimum Measuring Area	Diameter 6 mm
Minimum Thickness Of Substrate	0.5 mm(0.02)
Operation Environment	Temperature -10 to 50
Storage Environment	-10 to 60C(-4 to 158F)

Key Features

Separate digital probes
A maximum range of 5000µm
Accuracy ±(2%+1µm)
Resolution up to 0.1µm
Display maximum, minimum and average
Red backlight over-limit alarm

Reference ACDIU Category Thickness Gauge

Product Details

0-5000 Um Coating Thickness Gauge EC-900, The EC-900 Thickness Gauge can non-destructively measure the thickness of non-conductive coatings on metal surfaces, as well as the thickness of non-ferromagnetic metal coatings on ferromagnetic metals (such as iron, nickel, and cobalt, etc.). Specific uses include measuring the surface paint or plating of iron and stainless steel. The thickness of the zinc layer, measures the thickness of the paint or plastic film on the surface of aluminum and copper.
