3D Acoustic Level Scanner Range 70 Meters

Quantity

Specifications

Brand EIP Enviro
Measuring range 70 meters
Process Pressure -0.2 3 bar
Power Consumption Max 1.5 W @ 24 VDC
Supply Voltage 20 to 32 VDC
Signal Output 4-wire 4 20 mA/HART/RS-485/Modbus
Preferred Applications Powders and solids
Process Temperatures -40to +185C
Emitting Frequency 2 KHz to 10 KHz
Hazardous Locations ATEX Certified for Intrinsic Safety

Key Features

  • Beam Angle of 70 Degree to cover the entire Silo Surface Area to show the Level, Volume, and 3D Profile of material inside the Silo
  • The 3D Level Scanner works well with the Dusty environment (Based on Law of Diffraction with the low frequency and higher wavelength the 3D Level Scanner penetrates dust effectively.
Reference AACUS Category Level Transmitter

Product Details

The 3D Level Scanner employs an array of 3 antennas to transmit low frequency pulses and to receive echoes of pulses from the contents of the silo, bin, or other container. Using 3 antennas, the unit measures not only the time / distance of each echo but also its direction with a beam angle of 3070 degrees. The devices digital signal processor samples and analysis they receive signals to provide very accurate measurements of the maximum level, minimum level, average level volume and mass of the stored contents and also generates a real time 3D representation/ profile of the contents within the container Hoppers for display on remote computer screen. The above technology, due to its acoustic nature and having specially designed material and the principle of resonance, has a self-cleaning ability.
  • The 3D Level Scanner has a Self-Cleaning ability and does not require any air for cleaning.
