Ecotech Ambient Toxic/Hydrocarbon analyser VOC 1000

Quantity

Specifications

Power 90 - 240 VAC 50/60 Hz| 3A
Weight 9 kg
Dimensions 48.3 x 36.2 x 13.3 cm
Range 0 - 200 ppm (0 - 1000 ppm optional)
Display 8.6 x 11.4 cm graphical display
Operating Temperature 0 - 40 C
Repeatability +/- 1 % full scale
Operating Humidity 0 - 95 % non condensing
Drift +/- 1 % of full scale (24 hours)
Relay outputs 5 programmable form A relays rated to 3A @ 230 VAC
Digital outputs RS232| Ethernet
Analog outputs 1 programmable 0 - 20 or 4 - 20 mA isolated output (optional 3 analog output board)
Connections 1/4 tube fitting connectors
Detector Flame Ionisation Detector (FID)
Oxidiser Non-methane gases
Response T90 Less Than 30 seconds
Support gases Hydrogen 35 cc/min Air 175 cc/min

Key Features

  • Flame ionization detector
  • Hydrocarbon detection from sub-ppm to 1000 ppm (Methane)
  • Automatic calibration at user-defined intervals
  • Electronic control of fuel, air and sample
  • Electronic back-pressure regulator with sample bypass system ensures fast response
Reference AABOH Category Gas Analyzer Brand Acoem

Product Details

ECOTECH VOC 1000 is designed tomeasure total, methane and non-methanehydrocarbon gases providing accurateand reliable measurement data.VOC 1000 analyser provides unparalleled flexibility and offerscontinuous, fully automated gas analysis over a broadrange of concentrations.The analyser is based on a Flame Ionisation Detector (FID) withelectronic control that delivers a small portion of the sample gasto the detector flame. During the combustion process, organic orhydrocarbon-based gases in the sample are ionised, then they aredetected by the instrument and reported as a concentration.BENEFITS Hydrocarbon detection from sub-ppm to 1000 ppm (methane) Programmable automatic calibration at user-defined intervalsor manual calibration Electronic control of fuel, air and sample Electronic back-pressure regulator with sample bypass systemensures fast response Programmable analog output ranges Automatic FID ignition, with automatic shut-off of sample,fuel and combustion air Graphical display and easy to use menu system Internal single or multipoint modules, with or without samplepump for pre-filtered (< 0.1 microns), non-condensing samples Multilevel concentration and fault alarms that result in an audibleand visually displayed alarm. Alarms may also be mapped torelays to control external equipment Supports hydrogen 35 cc/min (blend 100 cc/min), air 175 cc/min.Hydrocarbon content must be < 1 ppm.
  • Programmable analog output ranges
  • Automatic FID ignition, with automatic shut-off of sample, fuel and combustion air
  • Graphical display and easy to use menu system
