Serinus 56 Total Sulfur analyser (TS Analyser)

The Serinus 56 Total Sulfur analyser deliversprecise and reliable performance at excellent value.It uses proven UV fluorescent radiation technologyand a thermal converter to measure TS in ambientair (LDL < 0.3 ppb, range 0-10 ppm).TS is measured by converting TS to SO2 using theexternal HTO1000 converter and then measuringthe resultant SO2 using the pulsed fluorescencetechnique.APPROVALSBased on the Serinus 50 Analyser which has US EPAand EN approval.BENEFITSThe Serinus range of analysers have been designedusing our experience and knowledge gained fromoperating large air quality monitoring networks formore than 35 years. The result, instruments thatintegrate seamlessly into continuous monitoringnetworks.Benefits include: Guaranteed performance with a two year warranty. Minimises time spent on site performingmaintenance through superior remote instrumentcontrol, diagnostic viewing and calibration. Enhanced operator safety through the use of12VDC internal voltages. Comprehensive data logging and remote viewingof over 200 operational parameters. Versatile interfacing through RS232, USB,Bluetooth, analogue and optional TCP/IP. Easier setup through an intuitive menu systemwith Quick Menu, advanced GUI and a largekeypad with tactile keys. Instant display of operational status usingilluminated traffic lights on the front panel. Removable flash memory stores 10 years of data,including up to 12 individual parameters and eventlogs. Operational parameters can also betransferred to memory for easy retrieval. Latest firmware updates can easily be installedusing the USB flash memory drive. Programming, viewing, downloading andemailing of data is made even simpler usingBluetooth connectivity combined with theEcotech Serinus Remote Android App. Reduced cost of spare parts, accessories andconsumable items through extensive use ofstandard components across the Serinus range. Rack slide design makes accessinginternal components and removing the analyserfrom a rack cabinet easy. AQM system power usage can be reduced due tothe instruments low power demand and its abilityto operate over a wide temperature range.Communications USB port (digital communication). Bluetooth (digital communication viaAndroid App). TCP/IP Ethernet network connection (optional). RS232 Port 1: Digital communication. RS232 Port 2: Multidrop port. Protocols: Modbus RTU/TCP, Bavarian,EC9800, Advanced.Inputs/outputs: 25 pin I/O port Menu selectable current or voltage output0-20 mA, 4-20 mA, or 0-5 VDC (opt 0-10VDC). Menu selectable offset of 0 %, 5 % or 10 %. Auto-ranging from 0-50 ppb to 0-20 ppm(between two user specified full scale values). 3 scalable analogue inputs, 0-5 v, 160 Vresolution. 8 logic level digital status inputs/8 opencollector digital outputs.Data logging: Removable USB flash memory drivethat stores data in the following formats: Instantaneous data from: 1, 3, 5, 10, 30, or 60minute intervals and 2, 5, 10, 30 seconds. Average data from: 1, 3, 5, 10, 15, 30 minutes, 1, 4,8, 12, or 24 hours. Data storage of 10 years of 12 parameters,1 minute data on 8 Gb memory.OPTIONS & ACCESSORIES HTO1000 thermal catalytic converter. External AC powered pump (capable ofoperating 3 analysers, excluding NOX). 12VDC power supply, Dual filter (particulate),Rack slide kit. TCP/IP network port. High pressure zero/span valves. Printed manualelectronic manual suppliedwith analyser. Internal long life, low power maintenance freepump (max 6 watts)
